1550nm FTTH CATV Direct Modulation Optical Transmitter

1550nm FTTH CATV Direct Modulation Optical Transmitter photo-1
1550nm FTTH CATV Direct Modulation Optical Transmitter photo-2
1550nm FTTH CATV Direct Modulation Optical Transmitter photo-3
1550nm FTTH CATV Direct Modulation Optical Transmitter photo-4
1550nm FTTH CATV Direct Modulation Optical Transmitter photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
B&A
Model Number:
OTD1500
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name B&A
Model Number OTD1500





Product Description

Features:

1550nm FTTH CATV Direct Modulation Optical Transmitter1550nm FTTH CATV Direct Modulation Optical Transmitter

1550nm FTTH CATV Direct Modulation Optical Transmitter

Features

Low noise high linearity Ortel-Emcore cooled DFB laser

GaAs technology up to 862/1000MHz

RF power digital automatic process technology control the laser driving RF power lever automatically according to RF signal level and channels, ensuring the best C/N, CTB and CSO

Excellent pre-distortion technology improves CTB,CSO and C/N

Built-in microprocessor accurately monitors laser output power and temperature

Front panel VFD displays the status parameters and function message

SNMP network management optional

Application



FTTH

Video optical transmission



Optical Characteristics



Parameter

Min

Typ

Max

Unit

Wavelength

1540

1550

1560

nm

Output power(1)

-----

10

------

mW

Optical Link Path Loss

----

11

----

dB

Frequency Range

47

-----

1000

MHz

RF input level

15

----

25

dBmV

RF input  impedance

------

75

-----

Ω

Flatness in band

-----

±0.75



dB

Input Return Loss

16

-------



dB

AGC control range

0

-------

15

dB

MGC control range

0

-------

15

dB

C/CTB

65

----

----

dB

C/CSO

63

----

----

dB

C/N

51

----

----

dB



Electric Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

Power Supply

Vps

110

220

240

VAC

Consumption

P

-----

----

24

W

 Environmental Characteristics

Parameter

Symbol

Min

Typ

Max

Unit

Operating Temperature

Tw

0

-----

50

Storage Temperature

Ts

-40

-----

85

Humidity

------

10

------

95

%
