Specifications
Automatic Laminating Machine1.high speed, stability, high precision
2.PLC controller
3. laminator:saves of time and labor
Laminating machine:
Major feature:
1.The vacuum suction-type feeding system can lead the paper accurately into the machine; Cycle stacking planes could stack the next batch paper well in a state of non-stop working , more efficient.
2.Bottom sheet use suction auto feeding, automatic tracking according to the face paper's speed.
3.New concept front gauge location, position high accuracy, bottom sheet never pull ahead.
4. Machine uses touch-screen/PLC/servo motor control system, circuit system is stable and could display the failure alarm automatically.
5. Automatic gluing, and the glue can be used circulatory, avoid glue waste.
6. Roller design scientifically, avoid glue fly out when the speed is high.
7. Pressure rollers adopt one side adjustment, convenient and fast.
8. Rocker controls wash roller's fluctuation, easy cleaning.
9. Counter designs scientifically, easy recording the amount you have been worked.
Main Specifications:
FM-E Series semi-automatic covering machine
Use and characteristics:
Body paper auto-feeding.
- Artificial front-push of upper paper on human design makes easy paper-feeding, exact positioning and fast working.
- Elastic front-margin positioning makes body paper never going ahead .and the paste front-margin of body paper and upper paper is controllable.
- It is suitable for the paste of 300g and above body paperboard and paperboard, the paste of paperboard pasted and A/B/C/D/E corrugated paperboard and the paste between corrugated papers.
- For the paste of type B and above corrugated paper with the length of 800mm and above, the long type of movable platen unit can be chosen .and for the paste between paperboards, the platen unit with adjustable pressure is optional.
We have 1100, 1300, 1450, 1600 4 kinds type.
Model |
FM1100 |
FM1300 |
FM1450 |
FM1600 |
Max. size |
1100x1100mm |
1300x1100mm |
1450x1100mm |
1600x1400mm |
Min. size |
350x350mm |
350x350mm |
350x350mm |
450x450mm |
Precision |
≤±1.5mm |
≤±1.5mm |
≤±1.5mm |
≤±1.5mm |
Speed |
100s/min |
100s/min |
100s/min |
100s/min |
Power |
14kw |
15kw |
15kw |
16kw |
Total length |
12.5m |
12.5m |
12.5m |
15m |
Total weight |
5000kg |
5500kg |
6000kg |
6800kg |
Technological parameter:
Model |
TMJ-1300A |
TMJ-1500A |
TMJ-1600A |
Max size of cover face |
1300mmX1100mm |
1500mmX1100mm |
1600mmX1100mm |
Mix size of cover face |
400mmX400mm |
400mmX400mm |
400mmX400mm |
|
Economic speed
|
0-100 piece/min |
0-100 piece/min |
0-100 piece/min |
|
Precision
|
±1.5 |
±1.5 |
±1.5 |
|
Power
|
10kw |
12kw |
12kw |
|
Size
|
10m x 2m x 2.4m |
10m x 2.15m x 2.4m |
10m x 2.15m x 2.4m |
|
Weight
|
About 6T |
About 6T |
About 6T |
1.The whole machine:
2. vacuum suctoon-type feeding system, feeding paper accurately,cycle stackingplanes
,so more efficient
4. Semi-auto bottom feeding unit:
feeding corrugated paper adopt suction automatic feed,feeding speed is automatic synchronous with surface paper
5. front guide position:
adopt elastic face set position,positioning precision. the corrugated paper never pull head.
5. Automatic corrugated board feeding unit
6.Surface board feeding unit.
7.board size:
