Specifications
automatic bottom paper-feedingsurface paper-feeding by hand
absorb type machine
automatic gule-mounting
Ⅰ.Introduction
FM-E style of laminator is a kind of machine which has automatic bottom paper-feeding and surface paper-feeding by hand. It is fit for lamination of color printing surface paper and corrugated paper, also the lamination of both cardboards. The laminated cardboards are smooth and beautiful and with fewer substandard products. The laminator is widely used for the package of electrical home appliances, food, fruit ,wine and light industrial products .FM-B style of laminator is made up of automatic bottom paper feeding ,air-suction, gum mounting ,water-mount ring, washing , automatic gum-mounting, control of light and electricity, pressing transmission and solidifying parts. This machine adopts liquid sense transmission, electricity front bar, and no bottom paper exceeded to finish the whole process of the gum mounting and pasting counting and solidifying of bottom and surface paper.
Ⅱ.Mode, Specification Parameter
- Model: FM-1600
- Max size of 1600*1300 mm lamination
- Min size of 350*350mm lamination
- Speed : 80pcs/min
- General power :5KW
-
Paper specifications
- surface paper≥180g/m*m cardboard
- bottom paper cardboard≥300g/m*m B,C,D style of single corrugated cardboard the bending of corrugated cardboard should not bigger than 10mm .
