Specifications
ir led panel1)Dimmable function available
2)13mm ultrathin ir led panel
3)Warranty provided
4)CE&ROHS, ISO9001
Superslim ir led panel 600*600mm:
Features:
1. Different size available for your need:
150*300mm, 300*300mm, 300*600mm, 600*600mm, 300*1200mm, 600*1200mm
2. Different watt available for your choice: 6w, 12w, 24w, 48w, 60w
3. 13mm ultra-thin thickness design, nice design with beautiful and elegant apperance for the light
4. Dimmable funtion available
5. Energy Saving ir led panel, best choice for replacing traditional lighting.
6. Special circuit design, each group of LEDs work separately, avoiding any problem of lighting output caused or
influenced by singe faulty LED.
7. With Less Light attenuation and a long l ife span of 50, 000 hours, The light can replace T5 fluorescent lamp,
which is much brighter than fluorescent lamp and better than most similar lighting products.
8. ir led panel with wide range of input voltage: AC85-264V
9. Instant start, no flickering, no humming.
10. New high efficiency constant current driver
11. No electrical wave, conforming to CE standard.
12. No Radio frequency interference.
We supply 6W 12W 24W 48W 60W ir led panel, high quality and best service with competitive price
Suitable for Hotels, Conference / Meeting rooms, Hospitals, factories & Offices, Commercial Purposes, Residential / Institution Buildings, Schools, Colleges & Universities workshops, Buildings, etc.
Specifications:
Model No.: FEP101. | |
LED Type |
Epistar SMD 3528 |
Power Consumption |
24/48Watts |
Size |
600*600*13 mm |
Fixing way |
In-built, Mounting, Suspending |
Frame Material |
Aluminum alloy panel |
LGP Material |
Acrylic |
Input Voltage |
AC85-264V |
Working Voltage |
DC24V |
Frequency |
50-60Hz |
Beam angel |
120 ° |
Fixing Ways |
In-built,Mounting,Suspending |
LED Quantity |
360/720pcs |
Operating temperature |
-10ºC-40ºC |
Storage Temperature |
-20ºC+60ºC |
Humidity Operating |
10º-80% |
Humidity Storage |
10-80% |
IP code |
IP41 |
Life span |
50,000 Hrs |
Energy saving |
Yes |
LED colors |
Cool White, Nature White & Warm White |
CCT |
5500-7000K, 3900-5500K, 2700-3900K |
Other sizes available |
300*300mm, 300*1200mm, 300*600mm, 600*600mm, 600*1200mm and custom sizes. |
packing: |
Carton packed |
CE & RoHS certificates | |
Warranty 2 years | |
Besides ir led panel, our factory also produce led flood light, led high bay light, led down light and so on:
ir led panel, led flood light, led high bay light, led downlight
