optical vacuum machine

Specifications

1.Certified ISO9001
2.Nice after-sales service
3.Strong technology support
4.Size can be customized
5.Good quality

   optical AR vacuum coating machine





What's the deatils of our  CCZK-1300 optical vacuum coating machine







1.Fast deposition speed and high production effiency ,coated film with excellent brightness and well adhesion.





2.Intelligent automatic control, easy to operate the machine without any experience.





3.Environment friendly ,no waste water and gas.





4.Manufacturing by CICEL latest technology,also approved CE and ISO international quality    management system    certification.







 specification of our CCZK- 1300 optical vacuum



coating machine





Feature:

1350 optical thin-films deposition machines(electron gun) can coat anti-reflection film,reflective film,filter film,beam-splitting film,bandpass membrane,dielectric film,high reflectivity film,color reflection film and so on. The membrane system range from 0 to 99 layer.This machine has a wide range of applications for  such field as auto reflective glass,telescope,spectacle lens,optical lens,luminescent cup and so on.If equipped with different evaporation source,electron gun, ionization source and film thickness gauge, It used for vapor deposition on the surface of metal,oxides,compound and other high melting point materials.It can also coat super hard film on the surface of glass.



application:

APS/ DSC / DSLR Camera Lens

PTV/ Liquid Crystal Projector Lens

Dichroic filter/ mirror

IR/ UV cut filter

DVD pick-up head and CCTV Lens

AR coating



Model	CCZK-1300G optical coater
Chamber size	Φ1300x1350
fixture	Arch-shaped 3 pieces of sector or single arch-shaped part
Pumping time	From atmosphere to 5.0x10-3Pa<15min (unloaded)
Ultimate vacuum	≤8x10-4Pa
Evaporation source	2 groups resistance evaporation, single power source, power: 5W
	E-beam,high pressure, adjustable, 6KV-10KV,power: 6KW
Ion source	Kerr source,double filament,power: 2KW
Film thickness controller	MDC-360C crystal film thickness controller or SQC-310, 9704 optical film thickness controller
Controlling system	Crystal touching screen and PLC make up the fully automatic controlling system
Inflation system	One way mass flow controller
Baking system	350, PID thermostatic control,9KW
configuration	KT-600,ZJP-300, 2X-70
Total / average power	35KW/25KW
Used for	Optical lens, glass products, ornaments, lamps,reflectors,plastic products
Remark	Can be designed according to customers request









Sample showcase:

















machine parts picture



Why choose us?



1.we are the alibaba Assessed 1year Gold supplier.



2.We are the a factury manufacturing vacuum coating machine ,best product capability,best quality control , best service.



3.Inspected by the inspection institution  of bureau veritas certification.



4.100%QC inspection before shippment.



5.CE/ISO listed ,competitive price.



Company information



   WENZHOU CICEL VACUUM MACHINERY CO.,LTD. is located binhai park in zhejiang wenzhou ,it is a professional enterprise of wenzhou large equipment R&D production,marketing and customer service as one of the company management, most of the staff have many years of production management experience and technology  of vacuum.assembly personnel with rich experience in production technology.





The company's main products are:high performance evaporation vacuum coating machine equipment,   magnetron supttering coating line,multi-arc ion plating equipment,magnetron supttering vacuum coating machine,the glass vacuum coating machine,optical coating equipment,light protective film professional vacuum coating equipment,the UV line automatic spraying line.















Clients of the company has covered all over the world,the main international trade in central Asia,Turkey,India,and so on.
