Specifications
1.Certified ISO90012.Nice after-sales service
3.Strong technology support
4.Size can be customized
5.Warranty: 1 year
1.Decorative vacuum coating equipment is evaporation-coated device in a vacuum chamber using electrical resistance heating, will close in the resistance wire on the metal wire vaporization melting, vaporization of the metal elements deposited on the substrate, but was Smooth high reflectivity of the coating to the surface of decorative items landscaping purposes.
2.The equipment is a reasonable structure, coating evenly into good-quality, pumping speed, the cycle of short, high efficiency and easy operation, low energy consumption and performance advantages of stability. Widely used in automotive, audio and various small appliances, computers, clocks and watches, toys, cell phones, reflective Cup, cosmetics, toys and other industries.
decorative lighting Ion coating machine model and technical parameter | |||||
model |
CCZK -700 |
DCCZK-900 |
CCZK -1000 |
CCZK -1250 |
CCZK-1400 |
Vacuum chamber structure |
700×H900mm |
900×H1100mm |
1000×H1200mm |
1250×H1350mm |
1400×H1600mm |
Power type |
Arc power, filament power, pulse bias power, direct current magnetic power, intermediate frequency magnetic power, sputter magnetic power, linear away source |
||||
Vacuum chamber structure |
Vertical front door structure, postposition sucking gas system, double layer water cooling chamber |
||||
Vacuum chamber material |
High quality stainless steel chamber |
||||
Ultimate vacuum |
6.0×10-4Pa |
||||
Total power |
40KW |
45KW |
50KW |
60KW |
75KW |
Occupy area |
W2m×L3m |
W2.5m×L3.5m |
W3m×L4m |
W4m×L5m |
W4.5m×L6m |
Other technical parameter |
Water voltage ≥0.2MPa, water temperature ≥0.2MPa, air pressure 0.5-0.8MPa |
||||
Remark |
Vacuum coating machine detailed configuration can be design according to customers product technological requirements. |
||||
It is applicable in decorative film in various plastic products, and glass. The aluminum-coated film is bright, delicate coating speed, high efficiency and simple operation, equipment stability.
We are able to supply customized vertical single-open and double-open or horizontal film coating machine according to the requirements of our customers.
Vacuum evaporation aluminum coating equipment main models and parameters
