Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > Factory Supply Straight Pcb Mount Terminal Block

Factory Supply Straight Pcb Mount Terminal Block

Name: Factory Supply Straight Pcb Mount Terminal Block
Brand: DFJM
SKU: 105930927

Factory Supply Straight Pcb Mount Terminal Block thumbnail-1

Factory Supply Straight Pcb Mount Terminal Block thumbnail-2

Factory Supply Straight Pcb Mount Terminal Block thumbnail-3

Factory Supply Straight Pcb Mount Terminal Block thumbnail-4

Factory Supply Straight Pcb Mount Terminal Block photo-1

Factory Supply Straight Pcb Mount Terminal Block photo-2

Factory Supply Straight Pcb Mount Terminal Block photo-3

Factory Supply Straight Pcb Mount Terminal Block photo-4

US$ 1.2 - 1.99 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

DFJM

Model Number:

DF-OBD002

Contact Supplier Request Quote Chat Now

Shenzhen Dongfeng Precision Components Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shekou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name DFJM

Model Number DF-OBD002

Type Other, PCB board for electric system, PCB board for electric system

Application Automotive

Gender Other, Male and female connectors

Product Description

1. 16 ways OBDII automotive connector

2. Produce in house,resonable price with excellent quality

3. 100% testing befere shippment

4. Plastic Material: PA66/PBT; Terminal: Brass,tin-plated or Nickel plated

5. Color: Black

6. We have our own mold, delivery time in 7 business day, and provide you factory price.

2. Commercial Standards and Specifications:

A. JASO D605 Multi-pole Connector for Automobiles.
B. JIS C3406 Low Voltage Wires and Cables for Automobiles.
C. JIS D0203 Method of Moisture, Rain and Spray Test for Automobile Parts.
D. JIS D0204 Method of High and Low Temperature Test for Automobile Parts.
E. JIS D1601 Vibration Testing Method for Automobile Parts.
3. Materials:

Description	Material	Finish
Housing	PA66 + GF15%	N/A
Terminal	Brass	Gold/Nickel Plating

4. Ratings:

A. Voltage Rating: 30 V MAX
B. Current Rating : 5A.
C. Temperature Rating : -40~85℃

5. Performance Requirements :

A.Terminal and housing between the retention force: 30N Min.
B.Contact resistance: 10 mΩ Max. (Single terminal)
C.Insulation resistance: 100 MΩ Min. 500V DC.
D.Connector Mating Force: 70N Max. Operation Speed : 100mm/min.
E.Connector Unmating Force: 50N Min. Operation Speed : 100mm/min.
F.Wave-soldering temperature: 250℃~270℃. (manual soldering temperature: 340℃~390℃.)

We can provide you all kinds of automotive connectors, wire to wire connectors,wire to board connectors, LVDS connectors, USB connectors, waterproof connectors, cable connectors, and so on..
