Specifications
wood cnc router1.Taiwan hiwin square guide rail
2. Japan panasonic SERVO motor
3. Italy HSD ATC spindle
4. vacuum table
wood cnc router XK1313ATC
Features
1. Excellent parts: Taiwan SYNTEC controlling system, Italy HSD air cooling spindle, Japan servo driving system, German ball-screws and Taiwan racks and square guide rails.
2. Different Processing tools of modular structure design, widely applied in engraving, cutting drilling and so on.
3. linear-type Automatic tool changing system with 6 tools in storage (optional)
4. Widely application
Furniture industry
solid wood furniture, wooden door, cabinet, etc.
Wooden products processing: wooden Speakers, wooden Clock, wardrobe, Sports Equipment
Musical instrument: 3D surface engraving and shape cutting.
Artwork making: photo frame, jewelry box
Electric industry: circuit board, insulation material, LED display screen
Technical parameters
Table Size |
1350*1900mm |
X.Y.X axis working area: |
1300*1300*300mm |
Reposition accuracy: |
±0.02mm |
Working Accuracy |
±0.05mm |
Max material height: |
300mm |
Table structure |
vacuum table |
movement |
Ball screw for Z,rack and pinion for X,Y |
Spindle Power |
HSD 9 kw |
Spindle Speed: |
18000rpm/Min |
Max-speed: |
≥60000mm/min |
Max-cutting speed: |
≥ 25000mm/min |
Driving motor |
Servo motor |
Working voltage |
AC380V/50HZ-60HZ 3-phase |
Command Code |
HPGL/G Code |
Controls |
LNC510i/SYNTEC system/Taiwan |
Command Language |
HPGL/G code |
