Help CenterXK45MT-D CNC Engraving Machine
Related Products
Specifications
CNC engraving machine1.Adsorb power:4.5kw
2.X Y Z axial :1300*2500*200mm
3.Spindle rotating speed :24000rpm/Min
CNC Engraving machine XK45MT-D
Feature:
1. The whole lathe is thicking,scientific welded,so it will not be become distorted.
2. Excellent parts :using imported straight _quadrated rail ,which imported from TaiWan.Two rows and four lines_rolling block devices that ensure it is high loading capacity and moves steadily.the imported screw rod from Germany is very precise.
3. has a power outage continued carving ,power failure recovery,processing time prediction function ,the real humanism design come true.
4.software has good compatibility and is compatible with several design software such as type 3/artcam/castmate/weitai and variety of CAD/CAM design software generate code which is processing.Ensure that the design barrier_free.
Specification:
ecification: (Horizontal drilling machine)
Model |
XK45MT-D |
Table size |
1440*3040mm |
X Y Z axis working area |
1300*2500*200mm |
X-Y movement |
Rack and pinion ,gear drive |
Z movement |
Ball screw drive |
Max cutting speed |
20000mm/Min |
Max speed |
35000mm/Min |
Repeat positioning accuracy |
0.05mm |
Resolutions |
0.025mm |
Adsorb power |
4.5kw /AIR cooling |
Spindle speed |
24000rpm/Min |
Inverter power |
5.5kw |
Horizontal spindle power |
4.5KW |
Inverter power |
5.5kw |
Working Voltage |
AC380/50-60Hz 3-phase |
Command code |
G code |
Drive motors |
stepper |
Collet |
ER 25~12.7mm.6mm,3.175mm |
Computer interface |
USB 2.0 |
Software |
Type 3 software/France |
Controls |
DSP0501(digital signal processor) for two spindle |
Packing dimensions |
2200mm*3200mm*1850mm 1400kg |
|
Equipment available |
a,Vacuum hold down b,Auto cut adjusting device c,Oil lubrication system d.Clamps and vacuum fitting |
