Specifications
2013 hot sale mini cnc roter machine1.0.8kw water spindle or 1.5kw
2.stepper motor
3.CE certificate
4.size:3030
2013 hot sale mini cnc router machine
Welcome to JInan Creat Star CNC Machinery Co.,Ltd
Proper Features for 2013 hot sale mini cnc router machine
1. Lathe bed is cast wholly and firmly with aluminum alloy and will not deform....
2. Desktop, small, easy to move and use, smart working job with high precision.
3. High speed driver stepper motor could enhance work efficiency.
4. Dust-proof and water-proof device makes the machine be preventive from dust and water and favorable for maintenance.
5. Humanistic design, the machine can be disassembled, so it is easily transported.
6.Applicablematerial:microlite,naturalgranite,seeingstone,marble,bowlder,bluestone,stone,glass, aluminum, iron, plastic and wood etc.
7. Applicable industry: mould and label signage making stone &metal industry.
Specifications for 2013 hot sale mini cnc router machine
Machine body |
Whole cast by aluminum |
working dimensions(X x Y x Z) |
300 x 300 x 80mm |
Max. Feeding height |
80mm or more |
Cutting thickness of material |
<25mm |
Driver type |
Stepper motor |
Blade diameter |
3.175mm,4mm,6mm (optional) |
Control system |
PC-control(NCSTUDIO) or DSP off-line control(USB) |
Running circumstance temperature |
0 - 45 |
Relative humidity |
30% - 75% |
Spindle Motor |
800w water-cooled/ 1.2kw air-cooled spindle motor |
Drive mechanism |
Germany imported ball screw |
Resolution |
0.01mm |
Max motion Speed |
4,200mm/min |
Max engraving speed |
4,000mm/min |
Rotating Speed of Spindle |
0~2,4000rpm |
Dictate Format |
G code |
Operating voltage |
AC110V/220V 50Hz/60Hz |
Pictures for 2013 hot sale mini cnc router machine
