Toe Socks Knitting Machine

Toe Socks Knitting Machine thumbnail-1
Toe Socks Knitting Machine thumbnail-2
Toe Socks Knitting Machine thumbnail-3
Toe Socks Knitting Machine thumbnail-4
Toe Socks Knitting Machine thumbnail-5
Toe Socks Knitting Machine thumbnail-6
Toe Socks Knitting Machine photo-1
Toe Socks Knitting Machine photo-2
Toe Socks Knitting Machine photo-3
Toe Socks Knitting Machine photo-4
Toe Socks Knitting Machine photo-5
Toe Socks Knitting Machine photo-6
US$ 4,000 - 4,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jacquard Knitting Machine
Production Capacity:
300 Pairs/day
Contact Supplier Request Quote Chat Now
Zhuji Hanjing Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGNO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Jacquard Knitting Machine
Production Capacity 300 Pairs/day
Place of Origin Zhejiang, China
Brand Name ROBOT
Model Number KR-608T
Voltage 220V/380V
Power(W) 3.5KW
Weight 330KG
Dimension(L*W*H) 115x76x170cm
Certification CNAS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description







6F   NO.: KR-608  plain machine

For socks type: Plain socks, TOE socks

Cylinder Diameter : 3+1/2”

Needles:56-280N
Running Speed (RPM):250-330
Drive Control:Servo Driver
Power Required:Drive Motor 0.85kw
Fan Motor: 0.75kw

Control Box: 0.80kw

Suction fan:1.1kw
Floor Space(W×L×H,cm) 150×120×240
Weight:Net Weight 300kg
Gross Weight 330kg
Packing size(W×L×H,cm) 115×76×170



Basic functions :

1.Each line can be woven into a main color and (four 5F) (six 7F) five secondary colors 6F.

2.Each socks can be woven into 16 colors

3.All computer-controlled weaving system (no drum).

4.To maintain high-speed operation to improve the internal triangle

5.Stepper motor with adjustable tension and textile yarn density

6.Yarn Road and Triangle by the electronic pneumatic control

7.Maximum range of 1,200 ranks flower model

8.Protect your computer by automatically sensing devices, electronic components

9.Automatic oil supply, automatic reading of needles, automatic reading speed

10.Pattern design system WINDOWS/2000/XP/7/8/10

11.Three-phase power 220v/380V and frequency 50/60Hz

12. Main parts are interchangeable with other popular models accessories

13. Auto-zero start position

14. Stalled electricity or other reasons to save flowers modle

15. Installing UPS systems can continue to weave an instant power failure

16. pattern type display panel







Features :

1.More enhanced functionality and improved quality of new models.

2.The full three-dimensional models can knit socks, to a wider range of socks for sample requirements.

3.Full elastic stockings to knit (the rubber band can be automatically stepping motor speed faster or slower, can be adjusted.)

4.Jacquard needle selection system faster, more accurate and more suitable for high speed weaving.

5.Uses a more advanced and accurate probe devices objectives to ensure a safer and more stable machine knitting.

6.Adopted a more lenient, clearer display, the computer data at a glance.

7.Followed by a two-way push-pin press needles, rotary speed of a small, fast and efficient.

8.All actions by the pneumatic device computer control device

9.Shuttle head yarn increased from 14 to 15. Therefore one can knit socks 16 colors.

10.Automatic control by the scores of motor density, can be adjusted.

11.Power control preset in 35FDD

12.Stickers on both sides and the socks with double-layer fabric features.

13.(Continuous power available) UPS function. Power failure stopped the engine can still provide power within 2 seconds, can remember three months of work procedures; re-started, the work can be a continuous process last.

14.16-step upgrade of the transmission.

15.Device can choose to use two sets of elastic cord, can be two different colors woven elastic.

16. Increase in of terry variable procedures and any jacquard terry , add half terry and the whole terry two states .



Needles parameters For ages:

Baby :96N 108N

Children:120N 132N

Student:132N 144N

Female:144N 156N

Men: 156N 168N

Feather socks: 4.5” 56N





Toe socks knitting machineToe socks knitting machineToe socks knitting machineToe socks knitting machineToe socks knitting machine
