Product Type: FS-X8(8FEED) FS-X12(12FEED)
FS-X8 Seamless underwear machine,Each is equipped with 16pcs Needle selector ; FS-X12 seamless underwear machines , each with 24pcs Needle selector ; can use natural fibers, synthetic fibers, rayon, nude spandex ,covered yarn etc,,,raw materials production single face garment, The main production of underwear , outerwear , sportswear, medical uses , such as clothing , if necessary, can also produce terry products.
FS-X8 FS-X12 series of seamless underwear machine designed from the beginning to fully study the various advantages and disadvantages of imported equipment , the integration of the characteristics of imported machinery , fully consider the needs of the market as well as on-site sampling conditions , improved conditions and optimized design features to improve product applicability , reliability and usability within .
Caliber,machine number, parameter
|
SyringeCaliber Needles
parameter |
12” |
13” |
14” |
15” |
16” |
17” |
|
28 |
1056 |
1152 |
1248 |
1344 |
1440 |
1536 |
|
26 |
960 |
1056 |
1152 |
1248 |
1344 |
1440 |
|
Function parameters
machine number |
FS-X8 |
FS-X12 |
SyringeCaliber |
12” 13” 14” 15” 16” 17” |
|
feed |
8feed |
12feed |
speed |
80rpm |
|
needle pitch |
12-32G |
|
Needle selector |
Each feed 2pcs,16pcs |
24pcs |
yarn feeder |
Each feed 9pcs yarn feeder, Can any jacquard , can complete single multicolor knit |
|
Yarn Clamps |
4,8feed double yarn clamps, other single yarn clamps |
|
The nose lifting |
Pneumatic and jog lift |
|
Fabric density |
Stepper motor control can be realized 3D knit |
|
Traction system |
Using ventilation system conducted stretch |
|
Yarn break induction |
Using infrared sensor alarm |
|
Yarn racks |
Floor racks and top racks two parts |
|
Lubricating |
Automatic timing , quantitative refueling |
|
Power outages technology |
Support for power protection, maintaining the status quo shutdown , power continued weaving, lower defect rate |
|
Tying technology |
Using Huff knitting needles can choose single or multiple double- lined elastic waist edge organization |
|
Terry |
According to the customer's needs to increase terry function configuration ( optional ) |
|
