AU Adaptor 12v to 240v

FOB Price

US$ 1.75 - 2.2 / Perch

100 Perches(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Description of AU Adaptor 12v to 220v

Technical Specification	Input Voltage	AC 100-240V
	Input Frequency	47Hz~63Hz
	Input Current	≤0.4A(AC Input Voltage 100V)
	Dash Current	≤50A(AC Input Voltage 240V)
	Power Factor	≥0.5(AC Input Voltage 240V, Internal Resistance<0.1Ω)
	Efficiency	≥77% at rated voltage
	Output Voltage	12V±5%
	Output Rated Current	1A
	Rated Power	12W
	Ripple Noise	≤120mV
	Start Delay Time	≤3S(under the Iput-voltage of AC110V)
	Working Temperature	0℃-50℃
	Storage Temperature	-20℃ to 70℃
	Humidity	5%-95%(under the condition of non-concentrated)
	Atmospheric Pressure	70 — 106Mpa
	Hi-pot Test	AC 3000V(Min), 3S, leakage Current≤5mA
	Insulation Resistance	≥10MΩ (standard atmospheric pressure, humidity 90%, DC500V)
Certificate	CE, FCC, ROHS, SAA, CB, GS, KC
Warranty	2 years
Feature	IC Program Design with low power consumption
	100% aging test
	MTBF50,000 hours under the temperature of 25℃ with maximum load(according to the standard of MIL-HDBK-217)

Detailed Pictures about AU Adaptor 12v to 220v
