X6232A Universal Swivel Head Universal Milling Machine Price

X6232A Universal Swivel Head Universal Milling Machine Price thumbnail-1
X6232A Universal Swivel Head Universal Milling Machine Price photo-1
US$ 5,500 - 6,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Tianjin, China
Brand Name:
ME
Contact Supplier Request Quote Chat Now
L&T Mechanical & Electrical Equipment Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Tianjin, China
Brand Name ME
Model Number X6232A
Type Universal
CNC or Not Normal
Voltage 2.2KW
Power(W) 2.2Kw
Dimension(L*W*H) 1700*1560*1730mm
Weight 1320kg
Certification ISO9001:2008 ; CE Standard Electrical Device
Warranty 18 Months
After-sales Service Provided Engineers available to service machinery overseas

  X6232A Universal Swivel Head Universal Milling Machine Price



We Manufacture. Stock. Distribute



Product Description

X6232A Universal Swivel Head Universal Milling Machine Price



Main Feature



Easy Operation

Hardened and Ground Table Surface

Automatic Feeds on X,Y Axis, Motorized Lifting and Falling of Table on Z Axis

Digital Readout (optional)

CE Standard Electrical Device

18 Months Warranty



Specifications

X6232A Universal Swivel Head Milling Machine

Table Taper (mm)

7:24 ISO 40

Distance from Spindle to Table (mm)

110-490

Distance from Spindle to Column

0-500

Spindle Speed (R.P.M)

35-1600

Table Size (mm)

1250*320

Table Travel(X*Y*Z) (mm)

600/320/380

Feeding Rang of Longitudinal, Cross Travel

(8step)22-555(Rapid 810)

Auto-feeding of Z-axis

560

T-slot (Number-width-distance) (mm)

3/14/70

Main Motor Power (KW)

2.2

Overall Dimension (mm)

1700*1560*1730

N.W./G.W.(Kg)

1320/1420



X6232A Milling Machine Standard Packing List



No.

Name

Model

Quantity

1

Milling Machine

X6232A

1

2

Milling Chuck

7:24 ISO40

1 Set

3

Inner-Hexagonal Spanner

5, 12

1 Set

4

Milling Tool Bar

ISO 40/ Φ32

1

5

Adapter Shaft

X622509228

1

6

Too; Bar

Φ32

1 Set

7

Guide Bar

X622509201

1

8

Holder

X622509101, 102

1

9

Wrench

S14-17 S21-24

3

10

Vice

160

1

11

Bolt

M12X30

4

12

Operation Manual



1

13

Quality Certificate



1

14

Packing list



1

milling machine price

 * You can also choose optional accessories, please contact our sales for details.

milling machine price

Sample Picture

X6232A Universal Swivel Head Universal Milling Machine Price

Aceessories

X6232A Universal Swivel Head Universal Milling Machine Price

Optional Cutters

X6232A Universal Swivel Head Universal Milling Machine Price




Packaging & Shipping

Plywood case/ Pallets
