Din 1 2316 Plastic Mould Steel

Din 1 2316 Plastic Mould Steel thumbnail-1
Din 1 2316 Plastic Mould Steel photo-1
US$ 0.5 - 2,000 MOQ: 1 Metric Ton
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
alloy steel
Thickness:
10-800mm
Contact Supplier Request Quote Chat Now
Dongguan City Yaoteng Special Steel Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard AISI, ASTM, BS, DIN, GB, JIS
Grade alloy steel
Thickness 10-800mm
Place of Origin Guangdong, China
Brand Name Yaoteng
Model Number din1.2316/sus420j2
Type Steel Plate
Technique Hot Rolled
Surface Treatment Other, black/bright surface
Application Other, tool steel
Special Use High-strength Steel Plate
Width 80-2300
Length 2000-5800mm

  din 1 2316 plastic mould steel





1.2316 tool steel in round bar, flat bar and plate in full lengths or bandsaw cut. 1.2316 is a chromium alloyed stainless plastic mould steel, which is characterised by good polishability, good hardenability with high hardness achievable after heat treatment. The steel has fair corrosion resistance giving this plastic mould stainless steel grade suitability for applications requiring good hygiene in industries such as medical and optical.





Product Description

din 1 2316 plastic mould steel



Chemical composition
Carbon 0.40% Silicon   0.75%
Manganese 0.50% Chromium 13.50%

 Specification:

   Round bar

Diameter(mm)

   Length (mm)



     10~800

   2000~5800



   plate/sheet

Thickness(mm)

    Width (mm)

  Length (mm)

     10~800

     80~2300

   2000~5800



round bar, flat bar and plate. Diameters can be sawn to your required lengths as one offs or multiple cut pieces. Rectangular pieces can be sawn from flat bar or plate to your specific sizes. Ground tool steel bar can be supplied, providing a quality precision finished bar to close tolerances.

Applications

1.2316 steel is ideally suited for plastic moulds, acid aggressive plastics, PVC or acetates and can be used with plastics containing abrasive fillers. 1.2316 is suitable to produce components for medical and optical applications where a high surface finish is required.
Forging

1.2316 plastic mould stainless steel can be forged by heating slowly and uniformly to 1000°C. After forging cool slowly in furnace or thermoinsulating material.
Annealing

1.2316 is commonly supplied in the annealed condition. Re-annealing will only be necessary if the steel has been forged or hardened. To anneal heat slowly to 780°C. Cool slowly in furnace to 600°C and then cool in air.
Stress Relieving

When heavy machining or grinding of 1.2316 plastic mould stainless steel has been carried out it is advisable to stress relieve in order to minimise the danger of distortion or cracking during the subsequent heat treatment. To stress relieve, heat the tools slowly to 650°C, soak for a minimum of two hours per 25mm of section and allow to cool down in the furnace to 500°C then continue to cool freely in air. The tools can then be finish machined, leaving on an allowance for final grinding after hardening and tempering.
Hardening

Pre heat the 1.2316 stainless steel to 600-700°C until heated through. Continue heating the 1.2316 to the final hardening temperature of 980-1050°C ensuring that the component is heated through. Protect the 1.2316 component against decarburisation by using a neutral salt bath, controlled atmosphere furnace or vacuum. Air cool or quench in oil.
Tempering

Heat uniformly and thoroughly to the selected tempering temperature and hold at heat for one hour per 25mm of total thickness. Double tempering is recommended. To achieve the best permutation of hardness, toughness and corrosion resistance it is recommended to temper at 250°C.



Temperature [°C] 100 200 300 400 500 600
Hardness [HRc] 56 54 52 54 53 34
Heat Treatment

Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of 1.2316 stainless tool steel.
Final Grinding

Select the correct grade of wheel in consultation with the grinding wheel manufacturer. Ensure the grinding wheel is in good condition by means of a suitable dressing tool. Wet grinding is a preferable option using a copious supply of coolant. If dry grinding is resorted to then use a very soft wheel.


Contact Information:               Mobile&WhatsApp:+86-15989907254             Skype:sophia.zhou306

                                        Email:sophia(at)





Product show

din 1 2316 plastic mould steeldin 1 2316 plastic mould steel



Packaging & Shipping

Our Packing  is easily loading and unloading. The way of packing has been widely loved by clients.And it can be customized.

Container condition:20'GP: maximum length≤5800mm, maximum weight 25 mts

                             40'GP: maximum length≤11800mm, maximum weight 25mts

din 1 2316 plastic mould steeldin 1 2316 plastic mould steel



Our Services

We have horizontal saw machine, vertical saw machine, CNC flame cutting machine, plane milling machine,

face milling machine, grinding machine equipment to meet customers’ requirements of the steel processing

din 1 2316 plastic mould steeldin 1 2316 plastic mould steeldin 1 2316 plastic mould steel



Company Information

Dongguan Yaoteng Special Steel Co., Ltd is a special steel  stockholders and suppliers of tool steel and mould steel.

On April 12, 2009, Yaoteng began to develop the international market, our products have been exported to Brazil, Turkey , Mexico, Colombia, Argentina, Dubai, Saudi Arabia, Syria, Iran, Egypt, the Philippines, Indonesia, Malaysia, Vietnam, India and other countries.



Our advantage:



  1.Large stocks for various steel grades:Over 5000Mt stock of regular grade and size

  2.Competitive price:long term cooperation with most China famous mill to intergrate mills' product line

 3.Fast delivery time:Own factories for peeling,milling,grinding and cuting etc

 4,Good after-sale service

din 1 2316 plastic mould steeldin 1 2316 plastic mould steeldin 1 2316 plastic mould steel



Main product
Main product
Hot work tool steel 1.2344,1.2343,1.2365,1.2581,1.2367,1.2713 etc.
H13,H11,H10,H21, etc.
SKD61,SKD6,SKD5,SKT4 etc.
Cold work tool steel 1.2379,1.2601,1.2080,1.2363,1.2842,1.2419,1.2510,1.2550,1.2767 etc.
D2,D3,D5,D6,D8,A2,O2,O1 etc.
SKD1,SKD11, SKS3 SKD10 etc.
Plastic mould steel 1.2083,1.2311, 1.2316,1.2738 etc.
P20, P20+Ni, 420 etc.
NAK80,ASSAB 718,718H,S136,S136H,M300
High speed tool steel 1.3355,1.3343,1.3247
T1,M2,M35,M42
SKH2,SKH51,SKH59
Structural alloy steel 1.7225,1.6511,1.7035,1.7220
4140, 4340, 5140, 4130,4150,4135
SCM440,SNCM439,SCM435
Carbon steel 1.1191,ck45,C45e,C45n,1.1730,1.1740
1020,1045, 1050
S20C,S35C,S45c, S50C,S55C,SS400
