Laser Marking Machine Laser Galvanometer Scanner Head

Name: Laser Marking Machine Laser Galvanometer Scanner Head
Brand: Superwave
SKU: 105875211
Availability: InStock

US$ 100 - 2,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Superwave

Model Number:

SW-LS

Shenzhen Superwave Laser Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Superwave

Model Number SW-LS

Laser Marking Machine laser galvanometer scanner head

Super High-speed Scan Head Specifications for High-speed Galvanometer Scanner
Specifications for Driver
1.1 Input Voltage Requirement	±24VDC 4AMX.RMS
1.2 Analog Signal Input Resistance	200K±1%Ω
1.3 Position Signal output Resistance	1k ±1% Ω
1.4Analog position Signal Input Range	±10V(Max)
1.5Position Signal Input Scale Factor	0.5 V/°
1.6Position Signal Output Scale Factor	0.5 V/°
1.7Oprating Temperature Range	0°C--40°C
1.8Diver Board Dimensions(LxWxH)mm	80x55x32
Specifications for Motor
2.1 Setting Time	±0.45ms
2.2 Linearity	99.9%
2.3 Scale Drift	40PPM/°C
2.4 Zero Drift	15µRad./°C
2.5 Repeatability	8µRad
2.6 RMS Current	3A(Max)
2.7 Peak Current	20A(Max)
2.8 Optical Aperture(standard)	Φ10mm
2.9 Maximum Scan Angle	±15°
2.10 Weight	110g
2.11 Operating Temperature Range	25°C±20°
2.12 Marking speed	500CH/S
2.13 Marking Accuracy	≤0.2mm drift
