Help CenterHot Work Die Steel H13 /1.2344 Round Bar Steel Price per Ton
Related Products
-
Lower Price Round Bar Skd61/free Sample Steel Material Skd61US$ 200 - 800MOQ: 5 Tons -
Forged Hot Work Mould Steel 1.2344/ H13/ SKD61 Round BarUS$ 2,416 - 2,658MOQ: 1 Ton
-
1.2343 Forged SteelUS$ 200 - 800MOQ: 5 Tons
-
H13 Esr Material Steel IngotUS$ 500 - 600MOQ: 5 Tons
-
H13 DieUS$ 500 - 600MOQ: 5 Tons
| |||||||||||||||||||
1.ChemicalComposition(%) |
|
||||||||||||||||||
2.Equivalent Grades |
H11/4Cr5MoSiV/SKD6 |
||||||||||||||||||
3.Form&SiZE |
|
||||||||||||||||||
4 Shape of the products |
1,round : forged steel , rolled steel , drawing steel ,polishing steel 2,Abnormal shape : quadrilateral steel, hexagons steel . 3,Flat steel |
||||||||||||||||||
5. Heat Treatment |
H13 tool steels are preheated to 816°C (1500°F). Then the steels are directly heated by increasing the temperature to 1010°C (1850°F) followed by holding for 15 to 40 mins. The steels are then air-quenched. |
||||||||||||||||||
|
|||||||||||||||||||
7. Forging |
H13 tool steels are forged at 1079°C (1975°F). For this type of steels, forging below 898°C (1650°F) is not preferable. |
||||||||||||||||||
8. Annealing |
H13 tool steels are annealed at 871°C (1600°F) and slowly cooled at 4°C (40°F) in the furnace. |
||||||||||||||||||
9. Tempering |
Tempering is carried out in H13 tool steels from 538 to 649°C (1000 to 1200°F) to obtain Rockwell C hardness of 53 to 38. Double tempering can also be performed in these steels for every one hour at the preferred tempering temperature. |
||||||||||||||||||
10. Stress Relieving |
When tools made from H13 tool steel are heavily machined or ground , the relief of internal strains is advisable before hardening to minimise the possibility of distortion. Stress relieving should be done after rough machining. To stress relieve, heat the component carefully to 700°C, allow a good soaking period (two hours per 25mm of ruling section). Cool in the furnace or in air. The tools may then be finish machined before hardening. |
||||||||||||||||||
11. Highlight advantage |
high hot strength and hardness
--good resistence to heat, good hot toughness, high resistance to temperature fatigue and wear in medium heat
--small heat deformation
--the tendency of the appearing of iron oxide skin are small in air-quenching
--excellent corrosion resistance
|
||||||||||||||||||
H13 Steel product details and application
steel producting process and quality control
warehouse steel stock- Yaoteng Mould Steel Co.,Ltd
Sales merchandiser:Winnie
Tel:+86-0769-33899333
E-mail:winnie AT toolsteel DOT net DOT cn
winnie AT otaisteel DOT com
Skype:928469037
Company Address: 3 fang,xiansha,Gaobu town,Dongguan City
