Sound control 230w sharpy 7r beam moving head light

Sound control 230w sharpy 7r beam moving head light

• Product Introduction :

Beam Spot230 use MHD230W projector lamp and the brightness output can be comparable with the 1500W searchlight. Has three functions: Spot, Beam , Wash . the light output is very smooth , equivalent to highly saturated palette. It is also equipped with a reflector implant , providing the perfect lighting calibration , quiet and fast . For professional lighting provides comprehensive cover , including 14 colors , 14 fixed pattern , 8 rotating gobos ; rotating 3-facet prism ; Futaba atomization ; linear mechanical focusing ; different speeds closed light strobe ; 0-100 % mechanical dimming ; 350W of power consumption and a beam angle of 4.8 ° . Small size , light weight, easy to transport. Suitable for live performances , TV, performances , stage and concert performance lamps.

• Product Features:

• Arclite MHD7R230 230W projection lamp

• 4.8°beam angle

• 1 color plate, 14 colors + white

• Bi-directional rainbow effect , speed adjustable

• a rotating gobo wheel , 8 rotating gobo + white

• a fixed gobo wheel , 14 fixed gobo + white

• Bi-directional speed adjustable Gobo rotation

• pattern overlay function

• Pattern Size: Outside diameter is 14mm, inside diameter is 10mm

• a rotating 3-facet prism , adjustable speed , bi-directional rotation

• rotating gobo / rotating prism combinations macro function

• atomization ( mixed dyeing effect )

• Futaba mechanical dimming system

• strobe effect , speed adjustable

• Motor focus from near to far

• 540°Pan scan , 270°Tilt scanning

• Auto Pan/Tilt scanning and position correction function

• 16 -bit precision smooth Pan/Tilt rotation

• Fast, quiet and precise Pan/Tilt positioning

• put out the lights MIB function

• Touch screen color LCD display

• 16CH/20CH international standard DMX channels

• DMX, stand-alone, master-slave , voice mode

• 3-Pin XLR connector signal input/output

• Fan cooling system

• 2pcs 1/ 4 fast locking

• Electronic ballasts and switching power supply

• Technical parameters:

• Input voltage : AC90-240V,50/60Hz

• Power consumption : 350W

• Lamp beads: Arclite MHD7R230W projection lamp

• Control signal : DMX 512,Master-slave,Voice,Self-propelled

• Control channels: 16CH,20CH

• Net weight : 17.5kg

• Gross weight : 18.5kg

• Product Dimensions : 340 (L)*420(W)*520 (H) mm

• Package size : 380 (L)*460(W)*560 (H) mm
