electrically conductive best aluminum foil tape
Advantages:
et ROHS
2.60 years of experience in manufacturing aluminum foil tape
3.Special quality and specification can be customized
Specifications:
1) Suitable in electronic and refrigeration fields due to its excellent thermal and electrical conductivity.
2) Material: aluminum foil.
3) Adhesive: solvent acrylic or water acrylic, synthetic rubber
4) Aluminum foil thickness: 30, 40, 50,60,80 microns.
5) protected by an easy-release silicone release paper
Aluminum Foil Tape with EMI function :
1.A nominal silicone release coated aluminum foil backing, combined with a high performance rubber resin adhesive. Aluminum Foil Tape Without Liner makes easy application.
2.Aluminum backing provides excellent reflection of both heat and light.
3.High quality adhesive with strong adhesion and holding power offers permanent sealing and bonding on Foil-Scrim-Kraft Facing joints and seams in HVAC ductwork application.
4.Good aging resistance both indoors and outdoors.
5.Low moisture vapor transmission rate offers excellent sealing and patching performance.
Physical Properties :
PROPERTIES |
UNIT |
VALUE |
TEST METHOD |
Total Thickness (Foil + Adhesive) |
Micron |
50-90 |
Micrometer |
Peel Adhesion |
N/25mm |
18 ~ 22 |
PSTC-1 |
Rolling Tack (11mm ball) |
cm |
10 |
PSTC-6 |
Adhesion to liner |
N/25mm |
£ 0.5 |
PSTC-4 |
Applying Temperature |
°C |
+10 ~ +40 |
---------- |
Temp. Resistance |
°C |
-20 ~ +120 |
---------- |
Application:
Aluminum foil tape can be applied to all types of transformers,mobile phones,computers,PDA,PDP,LED displays,notebook computers,copiers and other electronic products,where electromagnetic shielding is demanded.
electrically conductive aluminum foil tape electrically conductive aluminum foil tape electrically conductive aluminum foil tape electrically conductive aluminum foil tape electrically conductive aluminum foil tape electrically conductive aluminum foil tape
