Door Accessory

Name: Door Accessory
Brand: ANBO,DIDA
SKU: 105806853

US$ 0.98 - 1.2 MOQ: 2000 Pieces

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

ANBO,DIDA

Model Number:

9013 series

Shanghai Anbo-Bona Security Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name ANBO,DIDA

Model Number 9013 series

Europe Standard passage lock body with 3 combinations

	9013
	for Euro profile cylinder with 15mm radius cam
	latch in convex shape for a soft closing of door, driven by both lever handle and cylinder
	deadbolt driven by cylinder, double-throw
	lockcase with 2 holes at both sides of follower and cylinder hole in 38mm hole-centre

9040T
	for passage
	latch in convex shape for a soft closing of door, driven by lever handle only

9040D
	for bathroom
	latch in convex shape for a soft closing of door, driven by lever handle only
	deadbolt driven by turn knob, single-throw for easy operation

Available backset: 35mm, 45mm, 60mm

Main market: Spanish market

Latch: Brass latch

Available backset: 45mm, 60mm

Main market: England

Latch: Zamak

Available backset: 45mm

Main market: German market

Latch: Brass

9040K
	zamak keys, in 6 differs
	latch in convex shape for a soft closing of door, driven by both lever handle and key
	deadbolt driven by key, double-throw


	exterior cylinder:	brass, Φ23x40mm
	deadbolt :	steel, CP, double-throw

	cylinder-button
	exterior cylinder options:
	VB-01: 3 standard keys in brass, 5 pins ranged in max 7 heights
	VB-01S: 5 security keys in brass, 6 pins ranged in max 6 heights
	supplied with aluminium escutcheon, fixing screws and installation template

VB-02/VB-02S
VB-01/VB-01S	exterior cylinder:	brass, Φ23x40mm
	deadbolt :	steel, CP, double-throw

	cylinder-button
	exterior cylinder options:
	VB-02: 3 standard keys in brass, 5 pins ranged in max 7 heights
	VB-02S: 5 security keys in brass, 6 pins ranged in max 6 heights
	deadbolt adjustable for asymmetric extension
	supplied with aluminium escutcheon, fixing screws and installation template

Type 2 of door lock

VB-03/VB-03S
	exterior cylinder:	brass
	deadbolt :	steel, CP, double-throw

	cylinder-button
	exterior cylinder opotins:
	VB-03 : 3 standard keys in brass
	option A - brass cylinder Φ20x40mm, 4 pins
	option B - brass + tube cylinder Φ25x40mm, 5 pins
	VB-03S: 5 security keys in brass , brass+ tube cylinder
	Φ25x40mm, 6 pins
	supplied with aluminium escutcheon, fixing screws
