ODM/OEM avaliable fiberglass reinforced polyester sheet,fiberglass polyester sheet
Is there any product that you need?
Is it really can be customized as per your requirement?
How to get personalized service?
Let’s find answers...
Accurate specifications ensure that we provide professional products
| ITEM | UNIT | VALUE |
| Density≥ | g/cm3 | 1.70~1.90 |
| Flexural strength≥ | MPa | 166 |
| Tensile strength≥ | MPa | 78 |
| Compressive strength≥ | MPa | 157 |
| Shear strength≥ | MPa | 68 |
| Impact strength≥ | kJ/m2 | |
| Flatwise | 90 | |
| Edgewise | 45 | |
| perpendicular to lamination in transformer oil at 25±2℃≥ | kV/mm | 14 |
| Insulation resistance≥ | Ω | |
| Under normal condition | 1×1014 | |
| After boil in water | 1×1011 | |
| Volume resistivity≥ | Ω.cm | |
| Under normal condition | 1×1011 | |
| After boil in water | 1×1010 | |
| 1MHz loss factor≤ | — | 0.05 |
| 1MHz loss relative dielectric coeff≤ | — | 5.5 |
| Arc resistance≥ | s | 180 |
| Heat deflection temperature≥ | ℃ | 200 |
| Flammability≥ | ||
| Oxygen index | — | 50 |
| UL-94 flame | — | 94-V0 |
| Water absorption≤ | % | 0.2 |
| Area of the sheets | mm | 1050×1230,1020×2040 |
Next let us see more details
ODM/OEM avaliable fiberglass reinforced polyester sheet,fiberglass polyester sheet
Product description of reinforced polyester fiberglass sheet
GPO3 Polyester Glass Sheet is made of alkali-free glass felt impregnated with polyester resin under heat and pressure process.
Where can we use the product?
Product application will make us a direct impression.
Product Application of reinforced polyester fiberglass sheet
1.Relays and Switches.
2.High frequency electronic equipments.
3.Electrical Cabinet.
What about the product line ?
How to ensure the quality ?
Do you want to know more details?
Go on....
From raw materials to finished products, every process is tested and controlled professionally and seriously by our professional machines and person.
How to send an effective inquiry for saving your time?
1.Response to your inquiries and questions within 24hours.
2.Existing samples provided on free,only charge the freight.
3.High quality products and competitive offer.
4.On-time delivery date.
