Mica electrical insulation tape,mica tape and mica roll
Description
Fire-Resistant Mica Tape is made from mica paper (phlogopite paper, muscovite paper and synthetic mica paper) and electrical grade alkali free fiberglass cloth which are laminated together by silicone resin (2 layers) or laminated together with polyester film (3 layers).
Depending on the different type of mica paper and different layers of lamination,
We supply a variety of mica tape type with very specific characteristics.
Features
Smooth surface with uniform thickness
Excellent electrical insulation
Excellent fire resistance
High flexible and soft
mica electrical insulation tape,mica tape and mica roll,mica tape,mica electrical insulation tape
Application
To be used for cable and wire industry
Available
Thickness 0.10mm to 0.14mm
Roll width: 5mm to 1000mm
Special dimension on request
Technical Data
Double - side tape Single - side tape
Mica Content ( %) >55 >60
Dielectric Strength (KV/mm) >8 >10
Tensile Strength (N/cm) >100 >60
Volatile matter content (%) <1.0 <1.0
Burning performance of Category A - 750’C-800’C
Wires and cables Category B - 950’C-1000’C
3A fuse for 90 minutes, 1KV/min no breakdown
Insulation resistance >1.0M Ohms
Phlogopite Mica Tape - Category A - 750’C-800’C
Synthetic Mica Tape - Category B - 950’C-1000’C
mica electrical insulation tape,mica tape and mica roll,mica tape,mica electrical insulation tape
Is there any product that you need?
Is it really can be customized as per your requirement?
How to get personalized service?
Let’s find answers...
mica electrical insulation tape,mica tape and mica roll,mica tape,mica electrical insulation tape
From raw materials to finished products, every process is tested and controlled professionally and seriously by our professional machines and person.
mica electrical insulation tape,mica tape and mica roll,mica tape,mica electrical insulation tape
How to send an effective inquiry for saving your time?
mica electrical insulation tape,mica tape and mica roll,mica tape,mica electrical insulation tape
1.Response to your inquiries and questions within 24hours.
2.Existing samples provided on free,only charge the freight.
3.High quality products and competitive offer.
4.On-time delivery date.
