Specifications
IEEE802.3/ 802.3u/ 802.3xPlug-and-play, auto MDI/MDI-X connection
12~36VDC power input
Interface
RJ45 Ports: 10/100BaseT(X) auto connection, F /H duplex or force work mode, and support MDI/MDI-X connection
Fiber Ports: 100BaseFX ports (SC/ST connector, optional)
Single-mode: 20, 40,60, 80, 120Km,optional
Multi-mode: 2Km
Wavelength: 850nm, 1310 nm, 1550nm
Alarm output interface: One relay alarm output. Support power, port link and network alarm
Indicator: Power, Port link, abnormity alarm indication, 10M/100M Rate
Technology
Standards: IEEE802.3, IEEE802.3x, IEEE802.3u
Forwarding and Filtrate Rate: 148810pps
Processing type: Store and Forward
System exchange bandwidth: 4.8G
Relay
Max voltage: DC30V
Max power input: 24VA
Power
Input Voltage: 24VDC (12VDC~48VDC)
Overload Current Protection
Support dual power backup
Mechanical
Dimensions: 136mm×52mm×105mm (H×W×D)
Casing: IP30 protection, Metal case
Weight: 800g
Environmental
Operating Temperature: -40 to 75°C
Storage Temperature: -45 to 85 °C
Ambient Relative Humidity: 10% to 95% (non-condensing)
Approvals
EMI: FCC Part 15, CISPR (EN55022) class A
EMS: EN61000-4-2(ESD),
EN61000-4-3(RS),
EN61000-4-4(EFT),
EN61000-4-5 (Surge),
EN61000-4-6 (CS),
EN61000-4-8,
EN61000-4-11
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
