Glass Textile Sleeving With Polyvinyl Chloride Resin Based Coating (PVC)
Negotiable
MOQ: 10 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
powerwell
Model Number:
2715
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fiberglass Insulating Cable SleevesNegotiableMOQ: 10 Meters -
Fiberglass Sleeving Coated With PVC ResinNegotiableMOQ: 10 Meters
-
Silicon Rubber Fiberglass TubeNegotiableMOQ: 200 Kilograms
-
2715 Fiberglass Sleeving With Pvc ResinNegotiableMOQ: 10 Meters
-
PVC Fiberglass Sleeving(VG-201)NegotiableMOQ: 10 Meters
Place of Origin
China
Brand Name
powerwell
Model Number
2715
Type
Insulation Sleeving
Material
PVC
Application
High Voltage
Rated Voltage
1.5-4.0Kv
Specifications
1.Good flexibility2.Excellent abrasion and cut-through resistance
715 (VG201) FIBERGLASS SLEEVING COATED
WITH POLYVINYL CHLORIDE RESIN
Description
This product consists of a fiberglass braid with an electrical grade polyvinyl chloride resin coating specially formulated for exceptional heat resistance and stability.
Features
•-20°C to 130°C (class B) operating temperature range.
•Good flexibility
•Excellent abrasion & cut-through resistance
Applications
wiring insulation for Grade B electrical machinery, wireless sets and domestic electric appliances.
Available Sizes
In continuous spooled lengths or cut lengths in 1000mm per piece
Colors
Black, yellow, white and natural. Other colors may be available on request
Technical Data
Inner Diameter and Wall Thickness (Table 1)(mm)
| Inner Diameter Wall Thickness | |||
| Size | Tolerance | Minimum | Maximum |
| 1-3 | ±0.20 | 0.2 | 0.6 |
| 4-9 | ±0.30 | 0.3 | 0.7 |
| 10-16 | ±0.50 | 0.5 | 0.8 |
| Property | Requirements | |||
| Bending after heating | No cracking or detachment of coating shall be visible after bending around mandrels after 72 hours at 100C | |||
| Bending at low temperature | No cracking or detachment of coating shall be visible after bending around mandrels while at - 25C | |||
| Proof voltage (kv) straight or mandrel with 25 mm electrode | ||||
| Central value | Room temp | Elevated temp | Damp heat | |
| Lowest individual value | 4 | 12 | 12 | |
| 2.5 | 0.8 | 0.8 |
||
