Personalized transparent pet coated film
Is there any product that you need?
Is it really can be customized as per your requirement?
How to get personalized service?
Let’s find answers...
Accurate specifications ensure that we provide professional products
| Type: | 6020/6021 | ||
| Item: | Flexible PET film/Rigid polyester film | ||
| Thermal class: | E | Gauge(micron): | 28-250 |
| Characteristics: | Transparent/milk white ,flat, low shrinkage, excellent insulation properties | ||
| UL approved | |||
| Properties | UnitNO. | 1# | 2# | 3# | 4# | 5# | 6# | 7# | 8# | 9# | Test method | |
| Thickness | micron | 28 | 36 | 50 | 75 | 100 | 125 | 150 | 188 | 250 | GB12802.2 | |
| Tensile strength | MD | Mpa | 200 | 200 | 200 | 182 | 185 | 175 | 170 | 172 | 180 | |
| TD | Mpa | 210 | 210 | 198 | 198 | 190 | 186 | 206 | 185 | 200 | ||
| Elongation at break | MD | % | 120 | 115 | 125 | 115 | 120 | 150 | 130 | 150 | 148 | |
| TD | % | 110 | 105 | 130 | 110 | 102 | 110 | 100 | 110 | 109 | ||
|
Shrinkage (150℃,30min) |
MD | % | 1.3 | 1.3 | 1.4 | 1.3 | 1.3 | 1.4 | 1.4 | 1.5 | 1.6 | |
| TD | % | 0.7 | 0.8 | 0.8 | 0.9 | 0.8 | 1 | 1 | 1 | 1 | ||
| Breakdown voltage | V/µm | 185 | 220 | 188 | 165 | 145 | 126 | 123 | 104 | 92 | ||
| Volume resistivity | Ω·m | 1.0×1014 | ||||||||||
|
Relative dielectric constant (48Hz-62Hz) |
- |
3 | ||||||||||
| Dielectric loss tangent(48Hz-62Hz) | - | 2.8×10-3 | ||||||||||
| Haze | % | 2.5 | 2.8 | 3 | 3.2 | 3.3 | 3.8 | 4 | 4.5 | 5.3 | GB2410 | |
| Light Transmittance | % | 87 | 86 | 86 | 86 | 86 | 85 | 85 | 84 | 83 | GB2410 | |
| Gloss (45°) | % | 128 | 128 | 128 | 128 | 128 | 128 | 128 | 121 | 121 | GB8807 | |
| Density | g/cm3 | 1.395 | 1.395 | 1.395 | 1.395 | 1.395 | 1.395 | 1.395 | 1.395 | 1.395 | GB12802.2 | |
| Flame retardancy | VTM-0 | VTM-2 | VTM-2 | VTM-2 | VTM-2 | VTM-2 | VTM-2 | VTM-2 | VTM-2 | ANSI/UL94 | ||
Note: There specifications are typical performance data for polyester film.They are not intended to be used as design data.
Next let us see more details
transparent pet coated film,transparent pet coated film,transparent pet coated film
Product description of transparent pet coated film
Where can we use the product?
Product application will make us a direct impression.
Product Application of transparent pet coated film
It can be used as an electrical insulation for flexible laminate with other substrates. Such as paper aramid and non woven.
In motor applications, selected types of polyester film (composite) can be used for ground insulation as slot liner and wedges, as well as phase insulation in wire and cable applications, it is ideal for mechanical barriers, Plain polyester film also can be used for packing and printing industry.
What about the product line ?
How to ensure the quality ?
Do you want to know more details?
Go on....
From raw materials to finished products, every process is tested and controlled professionally and seriously by our professional machines and person.
transparent pet coated film,transparent pet coated film,transparent pet coated film
How to send an effective inquiry for saving your time?
transparent pet coated film,transparent pet coated film,transparent pet coated film
1.Response to your inquiries and questions within 24hours.
2.Existing samples provided on free,only charge the freight.
3.High quality products and competitive offer.
4.On-time delivery date.
