Beer Can Filling Line

Beer Can Filling Line photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Cans
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 5.5KW
Place of Origin Zhejiang, China
Brand Name weichi
Model Number GT7B20Q-FGJ250
Dimension(L*W*H) 3400*1950*1900mm
Weight 4000kgs
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas

Specifications

4 capping heads
20 filling heads
For beer and other CSD
Capacity:30-150cans/min



     This machine is suitable for filling and capping of beer,cola,soda and so on. It adopts isobaric pressure   filling principle. The main electric elements adopt “Mitsubishi” PLC, frequency converter and proximity switch.



     Set up the production speed on touch screen. Machine alarm automatically of all common malfunctions and show the cause and position of malfunction, PLC detect and decide to continue or stop the machine according the level of malfunction.

Specifications:

The number of capping head 4

The number of filling head :20

Production capacity:30~150 cans/min

Can Height:122~160mm

Can Diameter:Φ65mm

Power:5.5kw

Weight:4000kgs

Dimension:3400×1950×1900mm

The production capacity is relate with the carbonate content.



 advantages:

1. Equip with remote computer control system;

2. Adopts import frequency converter, adjust filling and seaming speed at will;

3. Equip with steam jet device according the customer requirement;

4. Filling quantity even and easy for adjustment;

5. Special filling valve is easy for clean.
