kama cargo truck

Specifications

SPECIFICATIONS	KMC3080P3
Engin Model	4102(FAW)
Bore/Stroke(mm)	102*118
Displacement(cc)	3857
Max Power(KW)	70.6
Rated Rotate speed(r/min)	3300
Cooling	in-line ,water cooling, 4-stroke
Overall dimensions(LxWxH)(mm)	5980*2020*2190
Cargo Box Size(LxWxH-inner)(mm)	4230*2060*550
Cabin	one and half cab,tiltable (1990)
Drive Type	4*4
Seats in cabin	3
Transmission	530
Curb Weight(Kg)	3610
Load Weight(Kg)	5000
Wheel Base(mm)	3300
Track(mm)   front	1785
back	1625
Max. Speed(Km/h)	90
Min turning circle dia(m)	12
Maximum gradeablity	≥45
Brake system	Air brake
Parking brake	spring energy cut air brake
Clutch model	Single plate, Dry type
Gearshift	5+1 speed, manually
Gearshift ratio	6.802,3.878,2.267,1.424,1.000;R6.154
Front axle	LS2080
Rear axle	1080
Final drive	6.333
Front tire	8.25-16
Rear tire	8.25-16
Battery(V)	24V
Power steering	WITH
A/C	WITHOUT
CD	mp3
Exhaust brake	with

  shandong KAMA Automobile Manufacturing Co.Ltd.is one of the big industry enterprise in china and one of the one-hundred strong corporations of mechanical industry in shandong province.it is in the "High-tech enterprises".It has 3500 workers,our products have been classified into mini,light,middle,heavy,and pickup in five series and more zhan 1000 models.
    shandong KAMA Automobile Manufacturing Co.Ltd.has advanced special production lines,such as pressing lines, coating lines,welding lines,etc.It has production capacity of 200 thousand trucks annually.it has got the quantity certificates of ISO9001 and ISO/TS16949,and passed the approval of CCC in the china.
    shandong KAMA Automobile Manufacturing Co.Ltd.persists in the policy of "costumers are the first and the best reputation".It has over 400 sales sites and KAMA service stations.It has already formed the efficient sale and service network.our products have already exported to many countries all over the world.
    our company has the aim of becoming bigger and stronger in manufacturing pickup trucks and trucks.we are trying to make KAMA the first base of automobiles and pickup trucks in china.
