Specifications
Auto feeding120W Lead-Free soldering station
eddy current heating welding machine
Feature:
1. High frequency eddy current heating ; Rapid heating and quick thermal recovery suitable for lead free soldering. Many types of tips are available with easy replacing.
2. Micro computer control; set temperature only by pressing keys; temperature calibrates digitally; more functions available, such as auto sleeping, auto shut-off.
3. Auto and manual ways of solder feeding optional. Imported motor,automatic feeding. More functions available and adjustable, such as feeding speed, feeding volumes, interval time etc.
4. Two types of feeding hose optional, easy to use. Long hose suitable for fixed soldering. It can be used as lead free soldering station only.
5. Pedal switch or manual switch is available. Soldering direction may be changed as needed and soldering can be agile and convenient.
Soldering machine
Model : |
BK3500 |
Set Temperature Range: |
200~500 C |
No load Power : |
<6W |
Max Power: |
120W |
Tin to Ground Resistance: |
<2Ω |
Tin to Ground Potential: |
<2mV |
Feeding Speed: |
14mm/s 35mm/s |
Feeding Volume(Auto Mode): |
0.5~123mm |
Feeding Interval Time: |
0~3.5s |
Diameter of wire usable: |
0.4 0.5 0.6 0.8 1.0 1.2 1.6 |
Spare parts
Model: |
BK3500 |
Heater : |
VH120 |
Iron handle: |
LF302 |
Soldering tips: |
BK200Series |
Iron Holder: |
BK502 |
Pedal Switch: |
Yes |
Manual Switch: |
Optional |
Packing list............................
Soldering machine....................................................................................1PCS
Solder iron+tin tube........................................................................1PCS
solder tip...................................................................................2PCS
iron support+sponge...........................................................................1PCS
power line...................................................................................1PCS
ground lead...................................................................................1PCS
user manual...................................................................................1PCS
warranty card...................................................................................1PCS
certification..................................................................................1PCS
