10' Open Side Shipping Container

10' Open Side Shipping Container:
none

10' Open Side Shipping Container

Product Profile

The shipping containers are made of high steel steel and are able to withstand extreme tempreture ranging from -40 °c to 70°c, and all have been certified by major Classification Society(CCS,BV,ABS,GL) completely conforming to International Standard.

Other Product Specifications

1)20ft/40ft/40ft hq/45ft hq
2) For general purposes

3) 20' Standard Container Dimension:20' x 8' x 8'6"
4) 40' Standard Container Dimension:40' x 8' x 8'6"
5) 40' hq Standard Container Dimension:40' x 8' x 9'6'
6) 45' hq Standard Container Dimension:45' x 8' x 9'6'

Product Picture

Dimension and Capacity

1)         Dimension

External:  length:  2991mm   width:   2438mm    height:  2591mm

Internal:   length:  2885mm    width:  2288mm     height:  2382mm

2)         Weight

Tare Weight:  1500 Kg

3)         Opening

Door opening: width:  2873mm         height:2270 mm

4)         Allowable Stacking Weight

NO TEST

5)         Cubic Capacity:15.7m3

6)         Special Feature

  i.              Lashing Rings and Lashing Bars

(1) Lashing rings are welded to right  bottom and right top side rail at corresponding recessed area of side wall.

Lashing ring Qty. . / right bottom or right top side rail: 3 pcs; total: 6 pcs.

(2) Lashing bars are welded on right corner post slot.Lashing bars Qty. / right corner post: 3 pcs; total: 6 pcs.

(3) Capabilities of pull load of every lashing point are as following:

Lashing rings on the side rails: 1,500 kg / each

Lashing bars on the corner posts: 1,000 kg / each

(4) Treatment of lashing ring / bar: Electro zinc plated

 ii.              Ventilators

Two (2) ventilators should be small type fabricated from A.B.S. resin by injection molding process. They will be secured to the panel recess near  corner post of right side walls, by means of three (3) Aluminum Huck bolts.

iii.              Customs Seal Provision

Customs seal provision is made on locking handle and retainer in accordance with TIR requirements.
