9 Port POE switch with 8 POE ports 25.5W/ 8 port POE switch/ POE Switch
*8 port poe switch
*9 port Ethernet poe switch
*48v high power 9 port poe switch
*CE,FCC,RoHS, ISO9001.
Detailed Product Description(9 port PoE switch)
- Name: POE Ethernet Switch, Power Over Ethernet Switch.
- PoE Ports: 8 port poe switch
- Transmission Rate: 10 /100 Mbps.
- Ethernet Standards: IEEE 802.3at
- PoE Power Output: 25.5 Watts
- PoE Budget: 110 Watts
- Bandwidth: 1.6 Gbps.
- Communication Mode: Full-Duplex & Half-Duplex.
- Function: POE, SNMP, VLAN Support
Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
- 1K entry MAC address table of the PoE Switch POE31804P-at with auto-learning and auto-aging
- LED indicators for monitoring power, link, activity and speed
- External power adapter supply
- IEEE 802.3at power on up to 4 ports
- Supply power to wireless access points and surveillance cameras over Cat-5 cabling
- 9 10/100 Mbps Ports with AutoUplink™
- Supports PoE power up to 25.5W for each PoE port
- Supports PoE power up to 110W for all PoE ports
- Supports PoE IEEE 802.3at compliant PDs
Specifications
Product |
9-PORT 10/100 SWITCH WITH 4-PORT POE+ |
Type |
POE31804P-at |
Network Ports |
9 10/100Mbps RJ45 PortsAUTO Negotiation/AUTO MDI/MDIX |
Power Pin Assignment |
Data provided over pairs over 1/2and 3/6 ,Power over |
PoE Distance |
100m |
Transmission Method |
Store-And-Forward |
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
100BASE-TX: UTP category 5, 5e cable (maximum 100m) | |
Performance Specifications |
Bandwidth:1.6 Gbps |
Network latency:Less than 20 μs for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmission | |
Buffer memory:96 KB embedded memory per unit | |
Address database size:1,000 media access control (MAC) addresses per system | |
Addressing:48-bit MAC address | |
Mean Time Between Failure (MTBF):190,000 hours (~ 21 years) | |
Acoustic Noise: 0 dB | |
Network Protocol and Standards |
IEEE 802.3i 10BASET |
IEEE 802.3u 100BASETX | |
IEEE 802.3x Flow Control | |
IEEE 802.1at DTE Power via MDI | |
IEEE 802.3at | |
Status LEDs |
System: Power, PoE Maximum Power |
Per Port: Link, Activity, Speed, PoE Active, PoE Fault | |
Power Supply |
Total Power Consumption: 120 W maximum |
PoE Watt budget: 110W | |
IEEE802.3at Power Consumption: 110 W maximum (Ports 1 – 4) | |
48VDC,2.5A power output; plug is localized to country of sale | |
Physical Specifications |
Dimensions (H x W x D):28 x 108 x 189mm |
Weight:0.65kg | |
Environmental Specifications |
Operating temperature: 0 to 55°C |
Storage temperature: -20 to 75°C | |
Operating humidity: 90% maximum relative humidity, non-condensing | |
Storage humidity: 95% maximum relative humidity, non-condensing | |
Operating altitude: 10,000 ft (3,000 m) maximum | |
Storage altitude: 10,000 ft (3,000 m) maximum | |
Electromagnetic Emissions |
CE mark, commercial |
FCC Part 15 Class B | |
VCCI Class B | |
EN 55022 (CISPR 22), Class B |
Model:POE31804P-at
Product size(mm) : 279 x 195 x 44mm
Installation Steps:
Department / Workgroup PoE Switch:
Providing 8-Port PoE in-line power interfaces, the POE31804p-at can easily build a power centrally-controlled IP phone system, IP Camera system and Wireless AP group for the enterprise. For instance, up to 8 PoE IP cameras can be installed around the corner in the company for surveillance demands or up to 8 PoE Wireless AP to build a wireless roaming environment in the office. Without the power-socket limitation, the Switch makes the installation of cameras or Wireless AP more easily and efficiently.
