Specifications
Decorative Wire Mesh1) High strength
2) Good osmosis
3) Excellent insulation
4) Heat preservation
Decorative Wire Mesh
Specifications:
1.10x10 mesh, 5x5 mesh, 5x4 mesh, 4x4 mesh, 2.85x2.85 mesh and so on
2.We can produce many specifications and use different packaging according to customers' requests!
Performance:
The product have good grid fixity, and high strength, good adhesion with cement mortar, excellent fitting positioning, excellent alkali resistance is very prominent, resistant to high alkaline substances concrete erosion. Strength retention rate> 90%, elongation <1%, the durability of more than 50 years. High elastic modulus 80.4Gpa, is can't reach by other chemical fibers.
Useage:
1.75g / m2 mesh fabric used in the reinforcement of thin slurry, to eliminate small cracks and scattered throughout the surface pressure.
2.110g / m2 mesh cloth is widely used in indoor and outdoor walls, prevent the various materials (such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion coefficient of wall crack and break
3. 145g/m2 mesh fabric used in the wall and be mixed in various materials (such as brick, light wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure, especially in the external wall insulation system (EIFS ).
4. 160g / m2 mesh fabric used in insulator layer of reinforcement in the mortar, through shrinkage and temperature changes by providing a space to maintain movement between the layers, prevent crack and rupture due to shrinkage or temperature change.
| TECHNICAL DATA SHEET | ||||||||||||
| Fiberglass Alkaline-Resistance Mesh | ||||||||||||
| Item Number | Yarn(Tex) | Mesh size(mm) | Density Count/25mm | Finished weight(g/m2) | Tensile StrengthX20cm | Woven Structure | Content of resin%(≥) | Color | ||||
| Warp | Weft | Warp | Weft | warp | Weft | Warp | Weft | |||||
| WS 5X5-70 | 45X2 | 200 | 5 | 5 | 5 | 5 | 7 0 | 550 | 850 | Leno | 16 | Any |
| WS5X5-80 | 67X2 | 200 | 5 | 5 | 5 | 5 | 8 0 | 700 | 850 | Leno | 16 | Any |
| WS 5X5-90 | 67X2 | 250 | 5 | 5 | 5 | 5 | 9 0 | 700 | 1050 | Leno | 16 | Any |
| WS5X5-110 | 100X2 | 250 | 5 | 5 | 5 | 5 | 110 | 800 | 1050 | Leno | 16 | Any |
| WS 5X5-125 | 134X2 | 250 | 5 | 5 | 5 | 5 | 125 | 1200 | 1300 | Leno | 16 | Any |
| WS 5X5-135 | 134X2 | 300 | 5 | 5 | 5 | 5 | 135 | 1300 | 1400 | Leno | 16 | Any |
| WS4X4-135 | 100X2 | 250 | 4 | 4 | 6 | 6 | 135 | 1000 | 1300 | Leno | 16 | Any |
| WS 5X5-145 | 134X2 | 360 | 5 | 5 | 5 | 5 | 145 | 1200 | 1300 | Leno | 16 | Any |
| WS 4X5-150 | 134X2 | 300 | 4 | 5 | 6 | 5 | 150 | 1300 | 1300 | Leno | 16 | Any |
| WS 5X5-160 | 134X2 | 400 | 5 | 5 | 5 | 5 | 160 | 1450 | 1600 | Leno | 16 | Any |
| WS 4X4-160 | 134X2 | 300 | 4 | 4 | 6 | 6 | 160 | 1550 | 1650 | Leno | 16 | Any |
| WS 4X5-165 | 134X2 | 350 | 4 | 5 | 6 | 5 | 165 | 1300 | 1300 | Leno | 16 | Any |
| WS5X5-250 | 134xX2 | 570 | 5 | 5 | 5 | 5 | 250 | 1700 | 2550 | Leno | 16 | Any |
| WS4X5-300 | 134X2 | 800 | 5 | 5 | 5 | 5 | 300 | 1800 | 2700 | Leno | 16 | |
