Help CenterKu Band Single HD LNBF
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Tenry
Model Number:
SL01
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangdong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
Tenry
Model Number
SL01
Specifications
1)Low noise figure2)HD ready
3)Low powder consumption
4)Easy installation
ku band universal lnbf 1)low noise figure 2)HD ready 3)low powder consumption 4)easy installation
ku band universal lnbf,c band lnbf ,digital satellite receiver
1)low noise figure
2)HD ready
3)low powder consumption
4)easy installation
5)high quality weather protection
| Image Rejection | 40 dB (Min.) | F/D Ratio | 0.6 | |||
| CrossPol. discrimination | 20dB(Min) | Input Reflector Type | Offset | |||
| Gain Flatness | 4.5dB(Over Band ) | Noise Figure | 0.7dB(TYP) 1.2dB(max) | |||
| L.O.Frequency | Low Band: 9.75GHz | Conversion Gain | 55dB(TYP) @25°C 50dB(min) | |||
| High Band: 10.6GHz | ||||||
| Input RF Frequency Range | Low Band: 10.7 - 11.7GHz | L.O. Stability | ±1.0MHz@25°C | |||
| High Band: 11.7 - 12.75GHz | ±3.0MHz @-40°C~ +60°C | |||||
| Output Frequency Range | Low Band: 950 - 2050MHz | L.O. Phase Noise | -40dBc(1kHz Offset) | |||
| High Band: 1100 - 2150MHz | -60dBc(10kHz Offset) | |||||
| -80dBc(100kHz Offset) | ||||||
| Output Return Loss | 8.0dB(2.3:1) | Output Power | 0dB (Min.) | |||
| Polarization Selection | V : 11~14V DC | Output Connector | 75Ω F-type female | |||
| H : 16~18V DC | ||||||
| D.C. Current Consumption | 120mA(TYP) 150mA(Max) | Operating Temperature | -40 °Cto +60 °C | |||
