Home > Transportation > Container & Fittings > Dry Van Container > Container Camp Workhouse for Workers
Container Camp Workhouse for Workers
US$ 3,000 - 3,500
MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Dry Container
Length (feet):
Other, 20'
Certification:
CSC
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Dry Container
Length (feet)
Other, 20'
Certification
CSC
Capacity
32.5cu.m
External Dimensions(l x W x H)(mm)
6058x2438x2591mm
Place of Origin
Shandong, China
Brand Name
singamas
Specifications
20ft open side container with ccs cert. easy load and unload| The container will conform to the following standards in their latest editions. | |||||||||||||||||||
| No.1:Handling of the Worker Dorm Type 1 | |||||||||||||||||||
| The container will be constructed to be handled under the following conditions without any permanent deformation or effect on its structural in | |||||||||||||||||||
| (1) Lifting full by its top corner castings by means of spreaders. | |||||||||||||||||||
Bitmap
| |||||||||||||||||||
| No.2:Technical parameter of Container dorm. | |||||||||||||||||||
| 1)Roof Load: 0.5 KN/sqm | |||||||||||||||||||
| 2)Wind Speed: 210km/h | |||||||||||||||||||
| 3)Temperature: -50°C-+70°C | |||||||||||||||||||
| No.3:Dimensions of Work Dorm . | |||||||||||||||||||
| Length | Width | Height | Remark | ||||||||||||||||
| 20HC | 6058mm | 2438mm | 2896 | Exterior Dimension | |||||||||||||||
| 5800mm | 2250mm | 2750mm | Interior Dimension | ||||||||||||||||
| No.4:Handling of the Worker Dorm Type 1 | |||||||||||||||||||
| The container will be constructed to be suitable for transportation in normal operating conditions by modes of: | |||||||||||||||||||
| (1) Marine-on deck or in cell guided by vertical or diagonal lashings | |||||||||||||||||||
| (2) Rail-on flat or container car secured at its bottom corner castings | |||||||||||||||||||
| No.5:Ratings of Work Dorm dorm. | |||||||||||||||||||
| Max gross weight(kg) | Tare weight(kg) | Payload(kg) | Remark | ||||||||||||||||
| Worker Dorm Type1 | 15000 | 2000 | 12000 | ||||||||||||||||
| No.6:Specification of work Dorm Type 1 steel structual | |||||||||||||||||||
| 6.1. Base and Floor The floor is composed of cross-member ,floor plate and bottom side rail. Bottom end / side rail t4.0m thick, SPA-H Floor Plate t18mm thick, PLYWOOD Cross-member t3.0mm thick, SPA-H 2) ROOF: Frame construction: 6mm welded steel profile; Roof Panel: t1.6mm thick, SPA-H Top end / side rail: t3.0mm thick, SPA-H 3) CORNER POSTS: Profile: Cold rolled 4.0 mm steel profile.. 4) WALL PANELS: Side Panel: t1.6mm thick, SPA-H PRESERVATION All the surface of the assembled container will have coating system as follows: Exterior Surface Epoxy zinc rich primer 30 Epoxy primer 40 Acrylic topcoat 40 Total 110 Interior Surface Epoxy zinc rich primer 30 Acrylic topcoat 40 Total 70 | |||||||||||||||||||
| No.7:Container dorm. Decoration Information | |||||||||||||||||||
| 1) Wall and Celling: Insulation material plus board | |||||||||||||||||||
| 2)Floor:18mm plywood floor , | |||||||||||||||||||
| 3)Insualtion material:EPS | |||||||||||||||||||
| 4)Window:Plastic steel | |||||||||||||||||||
| 5)Door:r Security door | |||||||||||||||||||
| No.7:Container dorm. Fittlings | |||||||||||||||||||
| 1)Desk with chair - with 6 dest and 6 chairs 2)electric distribution box 3) light - 2 pieces 4)flush-mounted switch - 4 each 5)flush-mounted socket - 4 each 7)Air condition -- without | |||||||||||||||||||
