This is a fully automatic plastic cup making machine integrate the Thermoforming part and Inverted cup stacking function.
The process of this machine is thermoform the plastic sheet to make cups then the cups through to the Inverted device into to the Stacker for Automatic Stacking, Counting and out of the machine tidily.
Application Area:
It is suitable for forming PP, PS, PVC & PET, it can be produced disposable cups.
Key Features:
1.This machine is controlled by PLC and using Touch-screen.
2.It is used the servo motor in Sheet-feeding Device and Pulling Device.
3.As this machine is fully automatic so it could help the plastic product manufacturer save the human resource and decrease production cost.
4.The fast speed of this machine is suitable for using in high level production line.
5.This machine is low pollution and wide range use for the manufacturer.
Main Technical Parameters:
| Power | 3-phase, 380V, 50HZ |
| Sheet Width | 500-650mm |
| Range of Sheet | 0.6-2.0mm |
| Max Forming Area | 600X300mm |
| Max Forming Depth | 120mm |
| Speed | 20-28 cycle/min |
| Air Pressure | 0.6-0.7Mpa |
| Air Consumption | 3m³/min |
| Water Consumption | 2T/hr |
| Machine Dimension | 12500X3000X2770mm |
| Machine Weight | About 10T |
Main Components
1.Gear Box
2. Servo Driving
3.PLC Control with Touch Screen
4.Normal Button Control
5. Pheumatic Control
6. Photoelectric Switch
Main Brand for Electrics and Pneumatics
1.SIEMENS
2.OMRON
3.MITSUBISHI
4.FUJI
5.FESTO
6.SMC
7. TAIWAN
Packing: Wooden-box
Delivery Time: Within 75days from the date of receipt 30% down payment of T/T or receive L/C
Port of Loading:Shantou Port
1.offer technical support
2.vedio debugging is available
service oversea is available
4. shipment arrangement is available
5. design for customers's request
6. OEM is welcome
7. customer's requst is welcome , any question will be replied in time
We are a leading manufacturer specialized in this field for more than 30 years,all of our clients speak highly of our machine quality level. Our factory is equipped with advanced integrated machine tools that enable us to produce high-quality, customized machines. We always strive to produce the most cost-effective and high-quality machinery to deliver total customer satisfaction. We export approximately 60 percent of our products to Southeast Asia, the Middle East, Africa and South America.All our Series products obtained CE certification.Besides, we can handle, design and assist you to build your package lines. Also, we can assist you to find supplier of container, tray, and film or other machines.We are able to offer you with best price and high quality with our accumulated technique. If you are interested in our machine, please contact us without any hesitation.
Mould Structure:
