Specifications
removable front louvre panel air in take louvres in filled with acoustic insulation meterial
1) Dimension
External: length: 6058 mm width: 2438 mm height: 2591 mm
Internal: length: 5856 mm width: 2346 mm height: 2352 mm
2) Weight
Max Gross Weight: 29,300 Kg
Tare Weight: 4,300 Kg
Max Payload: 25,000 Kg
3) Opening
Side Door opening : width : 800 mm height: 1805 mm
Rear door opening: width: 2326 mm height: 2288 mm
Front door opening: width: 2268 mm height: 2309 mm
4) Allowable Stacking Weight :192,000 kg
5) Special Feature
1. Checkered plate in which applied with three devices of Sewage sump tank, Drain hole and Fuel receptacle.
2. Facilities such as Installation plate, Tank mounting bracket, applied on the base structure.
3. Detachable blind window applied on the front end while fixed blind window on the rare end.
4.One repaired door in each side.
5. Facilities such as sound attenuator-fixing box, alarming apparatus fixed box, Emergency stop installation box and Supply installation box applied on the side panel.
6. Facilities such as Smoke vent joint, Muffler mounting plate, Water-adding mounting plate applied on the roof panel.
7. Punched metal plate could be applied inside the container and rock wool filled between it and container could be used to heat protection and sound absorption.
