airless tip for airless paint sprayer
1.Product information
• Highest quality tungsten carbide assures longest life and durability
• Insertion and knockout tool for no fuss assembly
• Supplied with a solvent proof tip seal and retainer
• Reversible design
• Retail packaging
• size from 2xx to 8xx
2.Detailed Size
RANGE :2XX TO 8XX
| size | detailed |
| 2xx | 211,213,215,217,219,221,225,227,231,235 |
| 3xx | 311,313,315,317,319,321,323,325,331,335 |
| 4xx | 411,413,415,417,419,421,423,425,427,429,431,433,435,439,441,443,445,451,455 |
| 5xx | 511,513,515,517,519,521,523,525,527,529,531,533,535,537,539,541.543,545,551,555,561 |
| 6xx | 611,613,615,617,619,621,623,625,627,629,631,633,635,637,639,641,643,645,651,655,661,665,671 |
| 7xx | 721,723,729,735 |
| 8xx | 817,819,821,827,831,833,835 |
Different nozzle size had different fan width,when you chose it need to condsider it.
| nozzle size | 2xx | 3xx | 4xx | 5xx | 6xx | 7xx | 8xx | |
| fan width | 4" | 6" | 8" | 10" | 12" | 14" | 16" |
3.How to understand the tip size
-Airless tips are sized using a 3 digital number such as 517. The first number has to do with the width of the spraying fan and the last 2 digits refer to the size of the hole or orifice the paint sprays through.
For example 508 and 515 both have the same fan width (approx. 10") but a different size hole. The 508 has a .008" hole and the 515 has a .015" hole. The 508 is used for thinner paints than the 515.
you can refernce the teble below :
Given a constant width (fan), the larger the orifice, the more material the sprayer will apply. (A larger orifice means greater paint flow).
Given a constant orifice size, an increasing fan width will apply a thinner coating of material to the surface because a given amount of material is distributed over a larger area.
5.Application
