10000-12000bph RCGF PET bottle filling machine
bottle filling machine
Usage
The line is mainly used for washing, filling and capping PET bottle which can fill non-carbonated drinks. Such as mineral water, pure water, wine and so on. Bottle washing, filling and capping are achieved in one machine. The contact time is shorten between material and the outside. And improved the health condtions, production capacity and economic benefits.
Character:
This water filling machine adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, aster and more laborsaving. the main machine adopts advanced PLC control technology. The key electric elements adopt mitsubishiomron Siemens, etc international famous products.
2,1. It is the fully automatic barreled water producing equipment, which is combined with machine, electronic and pneumatic components.
2. It integrates bottle washing, filling and capping in one unit.
3. This filling line is automatic.
Model |
RXGF16-16-6 |
RXGF18-18-6 |
RXGF24-24-8 |
RXGF32-32-10 |
RXGF40-40-12 |
Capacity |
4000-5000 |
5000-6000 |
6000-8000 |
8000-10000 |
16000-18000 |
|
can bottles type (mm) |
(Bottle Diameter):φ50-φ100;(Height):150mm-310mm |
||||
pressure of washing bottle(mpa |
0.2-0.25 (MPa) |
||||
|
watering consumption(kg/h)
|
1200 |
1500 |
1800 |
2400 |
3200 |
compressed air pressure(mpa) |
0.6 -0.8 |
||||
|
Air consumption(m3/min)
|
0.1 |
0.4 |
0.4 |
0.5 |
0.8 |
|
Total power (kw) ) |
2.2 |
3 |
4 |
6.2 |
7.5 |
|
Total weight (kg) ) |
2500 |
2800 |
3500 |
6000 |
8500 |
|
Dimension (mm)
|
2350x1750x2250 |
2480x1960x2250 |
3010x2180x2400 |
4000x2200x2500 |
4650*3300*3400 |
bottle filling machine bottle filling machine bottle filling machine
bottle filling machine bottle filling machine bottle filling machine
bottle filling machine bottle filling machine bottle filling machine
bottle filling machine bottle filling machine bottle filling machine
