Expandable & Modular Irrigation Controller

Specifications

Professional irrigation controller,expandable modular design:3, 6, 9 or 12 stations;three programs (A/B/C) with four start time.

Key Words: irrigation controller, irrigation timer, watering timer, irrigation programmer, landscape, watering, lawn



Product Overview

The Modular & Expandable controller, a kind of water efficient products for residential and commercial turf and landscape irrigation, is widely applied to home lawn, public parks, commercial centers, recreational sites, sport fields, memorial parks and other landscape areas. This product can automatically control and effectively save water resources when irrigating.



Features

1) Dial control for easy programming

2) Expandable modular design: 3, 6, 9 or 12 stations

3) Three programs (A/B/C) with four start times each, independent programming handles many different watering requirements

4) 1 minute to 6 hours run times per station

5) Water budget 10% to 150% / seasonal adjustment

6) Programmable pump start/master valve by station

7) Detachable faceplate for remote programming

8) High temperature & Large LCD display for simplified programming, easy to read for schedule review and entry

9) Choice of independent day scheduling options, days of the week, odd/even or 31 day interval for maximum flexibility.

10) Base model 3 stations with pump start/master valve

11) Each module for 3 stations, up to 3 modules for 6, 9, 12 stations

12) Rain sensor with on/off capabilities

13) Programmable pause between stations

14) Memory backup for programming

15) Excellent insurance against unreliable power. Superior surge protection and  self-diagnostic short circuit protection, microcircuits are protected from electrical spikes, no fuses to worry

16) With CE certificate.



Specifications



Transformer input: 120VAC, 60HZ or 230VAC, 50/60HZ

Transformer output: 25VAC, 1.0AMP

Station output: 24VAC, 0.56AMPS/per station

Operating temperature: 0-150

Dimension (L x W x H): 10" x 4.5" x 9".
