Product Overview
The ODH08E Conventional Fire Alarm Control Panel is a 24volt, 8 zone, Class B, Conventional Fire Alarm Control Panel. It is designed exclusively to meet the latest market requirements and microprocessor technology, with stand-by batteries (two sealed acid storage batteries) and reserved space for installation. It has functions of operation indication, fault indication, alarm indication and cable checking for short circuit or broken circuit. The highly cost-effective ODH16E can be used in low-sized applications.
Characteristics
Style B (Class B) Initiating Device Circuits (IDCs) accept two-wire smoke detectors and any normally-open contact devices
One set of volt free changeover contacts operable on fire
One set of volt free changeover contacts operable on fault
Non-latching zones facility
Class change input for remote control
Zone and alarm disablement
28V 125mA fused supply permanently available
28V 300mA fused supply available for fire alarm bells or sounders
Passive repeater available
Specifications
AC Power: AC220V±10% 50Hz, 2.0 amps, minimum 14 AWG wire (2.0 mm²) with 600-volt insulation.
Battery: Sealed lead-acid batteries, Maximum battery charger capacity: 4AH battery
Total 24 V system power: 3.0 amps
Zone Capacity: can be connected with 20 fire detectors and infinite manual call points
Fire & Fault Contact Outputs: 1.0 amps DC24V or AC125V
Using environment: Temperature: 0°C~50°C Related Humidity: ≤95% (40±2°C)
Dimensions: 265×335×87mm (length × width × depth)
Our service:
1.your inquiry related to our products or prices will be replied in 12 hours
2.well-trained and experienced staffs to answer all your enquires in fluent English
3.OEM&ODM,any your customized products we can help you to design and put into production
4.Protection of your sales area, ideas of design and all your private information
5.Deliver by air mail or ship for your orders
Trade Term:
1.Payment detailsT/T & western union optional;
2.Minimum Order 1000pcs(accept trial order);
3.Delivery Details within two weeks (Sample can be delivered within 3 days);
4.Discount are offered based on order quantity
