Help CenterLiquid Packing Machine/automatic Beverage Filling Machine
Related Products
-
Automatic Flow Pillow Packing MachineUS$ 10,000 - 50,000MOQ: 1 Set -
Automatic Flow Hamburger Packing MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
Price for Automatic Vacuum Packing MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
Modified Atmosphere Packing Machine TM170A Food Fresh MachineUS$ 1,650 - 20,000MOQ: 1 Set
-
Automatic Fresh Milk Packing Machine for pp BagUS$ 1,650 - 20,000MOQ: 1 Set
Specifications
Liquid & Thick Liquid Automatic Packaging Machine1.PLC ,touch screen control
2.high speed
3,full stainless steel
Specifications
Model |
XD8-200A |
Working position |
eight-working position |
Pouch material |
Laminated filmPEPP etc. |
Pouch pattern |
Stand-up, spout, flat |
Pouch size |
W:100-210mm L:100-350mm |
Filling range |
10-1000ml (to be customized 3000ml) |
Weigher accuracy |
±1% |
Speed |
≤50pouches/min(The speed depends on the product status and filling weight)) |
Weight |
1200KGS |
Voltage |
380V 3phase 50HZ/60HZ |
Total power |
3KW |
Compress air |
0.6m3/min(supply by user) |
Function and Characteristics
1.Easily operated,PLC system control,with touch screen.
2.Frequency conversion adjust the speed.It can be adjusted within the range for the needs of the reality in production.
3.Automaitc Checking :no pouch or pouch open error,no fill ,no seal,no waste of the pouches.
4.Safty device:Machine stop at abnomal air pressure,heater disconnection alarm.
5.The width of the bags can be adjusted by electrical motor.One button adjust the width of clipper,easy operation and save time.
6,Less pollution ,avoid polluting the environment in the production.
7.The part touching teh product and packing bags is full of stainless steel,accord with the food hygienic requirements,guranteehygiene and security of food
811.The packing bag suits in extensive range, suit for multi-layer compound, monolayer PE , PP and so on Preformed bag made by film and paper.
