P31.25 Stage Background Led Digital Display Screen

FOB Price

US$ 501 - 2,001 / Set

1 Set(Min. Order)

Port ShenZhen
Payment TermsT/T Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	ZXSheng
Model Number	stage background led digital display screen-P10FA	Usage	Outdoor
Tube Chip Color	Full Color	Display Function	Video
Pixels	Other, 31.25mm

Packaging Details

plywooden case
flight case

Product Description

Specifications

stage background led digital display screen
1.vivid picture
2.lightness and thinness
3.low power consumption
easy to install

stage background led digital display screen

larger led display for advertising

Led curtain screen is suitable for television studio and digital stage,it can show virtual images and color effects.In the field of art stage designing,the product performs outstanding artistic charm with its unique feature of permeability,lightness and thinness.It can be used in the large-scale song and dance soiree,fashion conference etc.

Main parameters:

Pixel information	pixel pitch	31.25mm
	pixel density	1024 dots/sq.m
	pixel composition	DIP546
	LED composing	4R2G2B
	LEDs Brand	Red: Optotech(China Taiwan)
		Green: Silan(China mainland)
		Blue: Silan(China mainland)
	LEDs Wavelength	Red: 615nm-635nm
		Green: 520nm-475
		Blue: 465nm-475nm
Viewing	White Balance	x=0.33 Y=0.33 5600° K(adjustable up to 9000°K)
	Brightness	>5000cd/sq.m
	Brightness Uniformity	Luminance Discrepancy<5%
	Colors	16777216
	Grey Level	256 levels
	Slot between Neighboring Modules	<1mm
	Recommended Viewing Angle(H/V)	110°/65°
	Recommended Viewing distance	>30m
	Malfunction pixel Rate	<0.02%
Dimension	Module Dimension	250mm×250mm
Dimension	Module Resolution	8*8
Power	Input Voltage	110±10V, 220±10V AC,50/60Hz
	Max Power Consumption	800 W/sq.m.
	Avg.Power consumption	300 W/sq.m
Ambient Conditions	Operating Temperature	-20~+60 °C
	Operating Humidity	10%~90%RH
	Ingression Protection Grade	IP65
Processing	Scanning Mode	Static scan, Constant current
	Refresh Frequency	180Hz_600Hz, Adjustable
	Signal Input	DVI, Composite Video for Live Video
	Supported Networking	Through LAN/ WAN, RS232/RS485
	Controller	PC based
	Software	Linsn
Other	Life Span	More than 100,000h
Other	Weitght	About15kg/sq.m

Company Profile

Shenzhen Oscarled Opto Co., Ltd.

Shenzhen Oscarled Co., Ltd. is a professional LED display manufacturer in China. Our company is engaged in research, production, sale and technical service together. We have rich experience in LED display industry. As one of the outdoor full color LED display and indoor LED screen leading manufacturers, we have professional R&D teams and after-sales service teams. Our products include taxi top led display ,outdoor full color LED displays, indoor full color LED displays, dual-color and single color LED displays, stage background LED screens, rental LED screens, traffic LED signs, curtain LED displays and so on. Our LED displays are widely used for advertising billboards, banks, retailers, hospitals, schools, expressways, governments, etc. We have won praise from domestic and overseas markets for our top-class quality and competitive products. Producing high quality, high technical and lower price LED display screens for our customers will still be our development goal.
