Specifications
hydrogen generator1) Capacity: 5-500Nm3/h
2) Gas Source: liquid ammonia
3) H2 Pressure: 0.5-1bar
4) Residual Ammonia: 3ppm
Automatic Hydrogen Generator through Ammonia Decomposition with Purification Device
Liquid ammonia is used as source for hydrogen generator through ammonia decomposition is. The liquid ammonia is vaporized and heated by decomposition with catalyst into mixed gas containing 75% hydrogen and 25% nitrogen. Base on the principle that the molecular sieve adsorbs different ammonia and water at different temperature, high purity gas is produced by heat regenerating through working at normal temperature.
The valve shifting and heating time will be controlled automatically for the whole equipment. No need special worker to operate and monitor it.
Technical Parameters of ZRAQ (FC) Series Equipments
Model |
Capacity (Nm³/hr) |
Feed Gas |
Product Gas (H2) |
|||||
Gas Source |
Pressure (Mpa) |
Dew-point (°C) |
Dew-point (°C) |
Residual Ammonia |
Pressure (Mpa) |
Temperature |
||
|
ZRAQ (FC) |
5-500 |
Ammonia vaporized from liquid ammonia |
0.05-0.2 |
≤-10 |
≤-65 |
≤3ppm |
0.05-0.1 |
Ambient Temperature |
