WZ Series Intelligent Temperature Sensor for Research Usage

standard export package

Specifications

Company Introduction

Yantai dongrun Instrument Co., Ltd. founded in 1998. It specializes in manufacturing online water quality analysis equipment, level meters, pressure gauges, flow meters, special temperature gauges and laboratory analysis equipment. Our company cooperates with Chinese Academy of Sciences and builds up a water analysis laboratory, mainly producing TOC analyzer, ammonia analyzer, fluorescence oxygen analyzer, etc. We have passed the ISO9001 certification. Our professional R & D team can provide technical supports to satisfy customer demand and our unique technologies can meet different working conditions.

product introduction

Series WZ(R)B temperature transmitter is a kind of modularization two-wire transmitter. It can be directly installed in the thermal resistance and thermocouple junction box. It directly amplifies and converts the temperature signal measured by the temperature element into standard 4~20mA current signals and transmits them to the fiduciary instrument of the lower level.

Technical parameter

Measurement range

Copper resistance-50-150 ℃
E type thermocouple 0-800 ℃
Platinum resistance -50-600 ℃
S type thermocouple 0-1600 ℃
K type thermocouple 0-1300 ℃


Operating ambient temperature -10 ℃ -70 ℃
Relative humidity ≤ 90%
Power Supply 24V DC ± 10%
Input signal Thermal resistance: Pt100, Cu100, Cu50
Thermocouple: K.E.S
Output signal 4-20mA DC two-wire
Basic error ± 0.5% FS
Influence of ambient temperature ≤ ± 0.5% FS/10 ℃
Load resistance 0-500Ω
Insulation resistance between the shell and input and output terminals
Insulation resistance ≥ 500Ω
Dimension φ45 × H16

company and trade show

qualification certificate

Welcome to contact us for more information!
Any questions, Please Contact me!
Tel: 0086-18766563778
