Temperature Transmitter

Company Introduction

Yantai dongrun Instrument Co., Ltd. was founded in 1998, specializes in manufacturing online water quality analysis equipment, material level meters, pressure gauges, flow meters, special temperature gauges and laboratory analysis equipment. Our company cooperate with the Chinese Academy of Sciences to build a water analysis laboratory, and the main products are TOC analyzer, ammonia analyzer, fluorescence oxygen analyzer, etc. We have passed the ISO9001 certification and has a professional R & D team, providing technical support to meet customer demand, particularly in the anti-corrosion, our company has a unique technology to meet different conditions of corrosion requirements.

Product Introduction

Series WZ(R)B temperature transmitter is a kind of modularization two-wire transmitter. It can be directly installed in the thermal resistance and thermocouple junction box. It directly amplifies and converts the temperature signal measured by the temperature element into standard 4~20mA current signals and transmits them to the fiduciary instrument of the lower level. The thermocouple temperature transmitter eliminates the need for expensive compensation wire. The users don’t have to consider the cold junction compensation. The lead resistance compensation is not needed for the thermal resistance transmitter. The transmitter module has a linearizer whose output current is proportional to the temperature. The transmitter module is shock-proof, moisture-proof and corrosion-proof. It can be widely used for the temperature detection and control of petroleum, chemical, metallurgy, electric power, paper, food processing, casting, heating treatment and research department.

Technical parameter

1. Measurement range

The copper resistance-50-150 °C  E type thermocouple 0-800 °C

Platinum resistance -50-600 °C   S type thermocouple 0-1600 °C

K type thermocouple 0-1300 °C

2.Operating ambient temperature-10 °C -70 °C

3.Relative humidity: ≤ 90%

4. Power Supply : 24V DC ± 10%

5.Input signal: Thermal resistance: Pt100, Cu100, Cu50

Thermocouple: K.E.S

6.Output signal:4-20mA DC two-wire

7.Basic error: ± 0.5% FS

8. Influence of ambient temperature: ≤ ± 0.5% FS/10 °C

9.Load resistance :0-500Ω

10. Insulation resistance: between the shell and input and output terminals

11. Insulation resistance ≥ 500Ω

12. Dimension: φ45 × H16
