USB/RS232 Card Reader,3 Tracks Reader, Credit Card Swiper

Communications

USB2.0,USB-OTG(Android 3.1 above)

Maximum power consumption

100 mW

Temperature

Commercial-grade:-20°∼ 60 °C

Industrial-grade:-20°∼ 60 °C

Humidity

90% non- condensing

Anti-static interference

15KV

Magnetic interference resistance

19Oersted

Vibration resistance

Amplitude 0.35mm,Frequency 10-55Hz,Three axis directions sweep vibration

Insulation Resistance

Hot and humid circumstances(40°,95%)Insulation resistance should not be less than 5MΩ

Dimensions

160mm(L) ×45mm(W) × 45mm(H)

Weight

180g

Magnetic card

Selectable tracks

yes

Read card

1/2/3tracks

Swipe

Double direction

Swipe speed

3 ~ 60 inches per second

Head life

Approx 500,000 passes

Parity and LRC checking

Built-in, audible and LED good read and error indicator

Cards supported

ISO 7811,AMMVA,CADMV

RFID card

Operating Frequency

13.56 MHz

Smart Card Interface

ISO14443-A, Mifare

Sensing Distance

About 0-5cm

Programmable sound

ON or OFF

Cards supported

ISO14443A,MifareOneS50,MifareOneS70,MF3 DESFIRE, Ultralight, ISO14443B ,SONY felica

PSAM card

Head life

Approx 200,000 passes

Communications

 USB

Cards supported

 ISO 7816-3

operating system

Win7, Win 2008 ,Vista, Win 2003, Win 2000, XP, Linux

IC Card

Cards supported

AT24C01A/24C02/24C04/24C08/24C16/AT24C64,SLE4432/4442,SLE4418/4428,

ISSI 24C01A/16,ISO7816-(1-4) (T=1, T=0)
