Fa8 Socket Led Tube 40W 2400mm SMD2835 216LEDS

Name: Fa8 Socket Led Tube 40W 2400mm SMD2835 216LEDS
Brand: hongzhun
SKU: 105368023

US$ 8 - 12 MOQ: 25 Pieces

Key Specifications

LED Light Source:

Epistar SMD2835

Warranty(Years):

Input Voltage(V):

100-240

Zhongshan Hongzhun Lighting Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

zhongshan

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source Epistar SMD2835

Warranty(Years) 3

Input Voltage(V) 100-240

Lamp Power(W) 45

Lamp Luminous Flux(lm) 40000

Lamp Luminous Efficiency(lm/w) 100

Color Temperature(CCT) Cool White

Working Temperature(℃) -25, 55

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum

IP Rating IP44

Certification CE, LVD, UL

Place of Origin China

Brand Name hongzhun

Model Number T8

Product Description

fa8 socket led tube 40W 2400mm SMD2835 216LEDS

Part No.	T840W2400
Optics Parameters	Light Source	216pcs SMD2835
	Luminous Flux(lm)	3900-4000LM
	CCT(K)	WW(3000K)/NW(4000K)/CW(6000K)
	CRI(Ra)	more than 75Ra
	Beam Angle	180 degree
	Light Attenuation ratio (%)	less than 3% in 30,000Hrs
	Lifespan (Hrs)	more than 50,000Hrs
Electric Parameters	Input Voltage(V)	85-265Vac
	Frequency(Hz)	50/60 Hz
	Input Current(mA)	180mA (@ 220 Vac )
	Total Power(W)	45W
	Power Factor	0.9
	Turn-on Time(S)	less than 0.05 S (@ 220Vac)
	Dielectric Voltage Withstand Test	3750Vac/1min
Structure Parameters	Material	Aluminum+ PMMA
	Size(mm)	2384*26mm
	Weight(kg)	0.83
	Water Proof(IP)	Indoor Use Only
Integrated Parameters	Operating Temperature	40 ~ 60 Centigrade
	Storage Humidity	0% ~ 95%R.H.
	Safety Requirement	CE
	Environmental Directives	RoHS
