Phenolic Film Faced Plywood

Name: Phenolic Film Faced Plywood
Brand: TIANYANG
SKU: 105367009
Availability: InStock

Shouguang Sunrise Industry & Trade Co., Ltd.

US$ 250 - 330 MOQ: 20 Cubic Meters

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

TIANYANG

Model Number:

004

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name TIANYANG

Model Number 004

Usage Outdoor

Grade First-Class

Main Material Poplar

Formaldehyde Emission Standards E1

Plywood Type 18-Ply Boards

phenolic film faced plywood

1.Description of Goods:

1) Size: 1220*2440mm,1250*2500mm or as per your request.

2) Thickness: 9-25mm

3) Core: hardwood,poplar,combi,birch etc

4) Film: black,brown

5) Glue: MR/WBP/MELAMINE

6) Usage: construction etc

7) Density: 500-600kgs/m3

10) Used times: more than 10 times

12) MC: below 14%

2. Features & Advantages:

1) flexible, inexpensive, workable and re-usable

2) resistance to cracking, shrinkage, splitting, and twisting/warping, used instead of plain wood

3) high degree of strength and very hard to bend

3.Mill Test Report:

*Film Faced Plywood 1220244018mm*
No.	Test Item		Unit	Normal Value	Test Result	Conclusion
1	Density		kg/m3	500-550	520	Pass
2	Moistrue Content%		%	6--14	8	Pass
3	Thickness Tolerance		mm	+/- 0.5mm	+/- 0.4mm	Pass
4	Length/Width Tolerance		mm	+/- 1mm	+/- 0.6mm	Pass
5	Bonding quality	Mean shear strength(fv)	N/mm2	≥0.70	1.98	Pass


		Mean apparent percentage wood failure (W)	%	/	80	Pass


6	Bending strength	Longitudinal grain	N/mm2	≥25	48	Pass

		Cross grain	N/mm2	≥21	41	Pass

7	Modulus of elasticity in bending	Longitudinal grain	N/mm2	≥5500	6250	Pass

		Cross grain	N/mm2	≥3550	4550
