The Best Spring Machinery Factory in China Top Spring Wire Rotary Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WNJ
Model Number:
CNC-650
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC 625 Best Seller of Torsion Spring Forming Machine in Mainland ChinaNegotiableMOQ: 1 Set -
CNC-625B High Quality Top Automatic Metal CNC Auto Spring MachineNegotiableMOQ: 1 Set
-
China Factori Professional CNC Metal Spring Roll Maker MachinNegotiableMOQ: 1 Set
-
2016 Hot Selling CNC-625B Solid Automatic Metal Spring Forming MachineNegotiableMOQ: 1 Set
-
New 2016 CNC-650 CNC 5 Axis Spring MachineNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
WNJ
Model Number
CNC-650
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
| Item Name | The Best Spring Machinery Factory in China Top Spring Wire Rotary Machine |
| Style | CNC-650 |
| Color | Grey/Blue |
| Wire Diameter of Coiled Material | φ2.5 -φ5.0mm |
| Max. Outside Diameter of Coiled Spring | φ100mm |
| Instruction Value of Wire Feed | ±0.01 - ±9999.99 |
Instruction Value of Cam |
±0.1° - ±359.9° |
| Savable System | 99 groups |
| Motor Power | 11KW (X-Y axis), 1.0KW (Z axis) |
| Power | Three phase 380V, AC ,50HZ |
| Weight | 3500kg |
PRODUCT PARAMETERS
- Equipped with the computer-controlled system imported from Taiwan and servo motor imported from Japan .
- This machine is for camdesign,set up spring with high speed and accuracy.And with stable good enough .
- Wire feed with the function of rotary wire,so it is easy to adjust .
- Computer interface displayed in Chinese and English which makes the operation easy .
- It is suitable for producing double torsion spring, straight spring, pagoda-shaped compression spring, rectangle spring, swirl spring and other different spring and special-shaped spring .
OUR SERVICE
- Two-years (computer ) &one-year (mechanical) warranty.
- Permanent technical service .
- One week free training with accommodation and food.
- Engineer can be sent aboard for installation, debugging and training.
MAIN PRODUCTS
COMPANY INFORMATION
CERTIFICATION
PARTNERS
AGENTS
FAQ
- What is your machine controller and motors?
- Controllers are imported from Hust, Taiwan. Motors from Sanyo,Janpan.
- Can you offer training in our plant?
- Basically, we have sales and service teams in Euro, Turkey, Korea,Japan, South American, India. If you are out of these countries, our enginner will be sent to your place for training if you need.
- How many years you exported? Do you have CE?
- Definitely, we have exported spring machines in past 9 years, and all of the machines have CE certificates.
