VMI Series Two -position Three Way Solenoid Valve

Name: VMI Series Two -position Three Way Solenoid Valve
Brand: round star
SKU: 105309227
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Standard or Nonstandard:

Standard

Structure:

Safety

Pressure:

Medium Pressure

Yuyao No. 4 Instrument Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Standard

Structure Safety

Pressure Medium Pressure

Power Solenoid

Material Brass

Temperature of Media Medium Temperature

Media Base

Port Size 1/4"

Place of Origin Zhejiang, China

Model Number VMI

Brand Name round star

Specifications

suit to water,hot water,gas,freon

VMI-A( N/C )PARAMETERS

G CONNECTION		G1/4”
ORIFICE SIZE (mm)		1.6	2.0	2.5	3	4
CV VALUE		0.07	0.14	0.21	0.25	0.35
PRESSURE (Mpa)	AC	0~1.3	0~1.1	0~0.9	0~0.6	0~0.35
	DC	0~1.1	0~0.9	0~0.7	0~0.4	0~0.2
MEDIUM/TEMPERATE		WATER,AIR,OIL(below 20CST ) / -5~80°C
VOLTAGE	AC220V	18VA
	DC24V	16W
BODY MATERIAL		BRASS/STAINLESS STEEL304
(In case of special voltage, please state with your order)

VMI-B( N/O )PARAMETERS

G CONNECTION		G1/4”
ORIFICE SIZE(mm)		1.6	2.0	2.5	3	4
CV VALUE		0.07	0.14	0.21	0.25	0.35
PRESSURE(Mpa)	AC	0~1.3	0~1.1	0~0.9	0~0.6	0~0.35
	DC	0~1.1	0~0.9	0~0.7	0~0.4	0~0.2
MEDIUM/TEMPERATURE		WATER,AIR,OIL(below 20CST ) / -5~80°C
VOLTAGE	AC220V	18VA
	DC24V	16W
BODY MATERIAL		BRASS/STAINLESS STEEL 304
(In case of special voltage, please state with your order)

VMI-C OMNIPOTENCE PARAMETERS

G CONNECTION		G1/4”
ORIFICE SIZE (mm)		1.6	2.0	2.5	3	4
CV VALUE		0.07	0.14	0.21	0.25	0.35
PRESSURE (Mpa)	AC	0~0.7	0~0.5	0~0.4	0~0.25	0~0.17
	DC	0~0.5	0~0.4	0~0.3	0~0.2	0~0.08
MEDIUM/TEMPERATURE		WATER,AIR,OIL(below 20CST ) / -5~80°C
VOLTAGE	AC220V	18VA
	DC24V	16W
BODY MATERIAL		BRASS/STAINLESS STEEL304
(In case of special voltage, please state with your order)
