T8 new design tube v shape lighting led
Specification
| Name | T8 new design tube v shape lighting led |
Power |
36w |
Input Voltage |
AC90-265v |
Size |
D26*1200mm |
Light Efficacy |
80lm/W |
Light Source |
SMD2835 |
Luminous Flux |
3880±100Lm |
Beam Angle |
270Degree |
Housing materials |
Aluminum |
Light Color |
Warm white/Nature White |
CCT |
2700-6500K |
CRI |
Ra≥70 |
Pictures show
Multi-sizes for choices
600MM 18W
| Material:/Aluminium Body+Milky PC Cover | SMD:2835 Luminous:1680±100Lm |
| Light transmittance :≥80% | Lifespan:≥50000H |
| Input Voltage:AC85V~265V | Efficiency:≥88% |
| Working frequency:50/60Hz | Rendering Index:70Ra |
| Power Factor:0.95±0.02 | CCT:2700-2800K,6000-6500K |
| Operating temperature:-20°C~45°C | SIZE:588mm (L)×D26mm |
900MM 25W
| Material:Aluminium Body+Milky | SMD:2835 |
| Light transmittance :≥80% | Lifespan:≥50000H |
| Input Voltage:AC85V~265V | Efficiency:≥88% |
| Rated Power:25W | Beam Angle:270° |
| Actual Power:25W | Luminous:2200±100Lm |
| Working frequency:50/60Hz | Rendering Index:70Ra |
| Power Factor:0.95±0.02 | CCT:2700-2800K,6000-6500K |
| Operating temperature:-20°C~45°C | Size:898mm (L)×D26mm |
1200MM 36W
| Material:Aluminium Body+Milky | SMD:2835 |
| Light transmittance :≥80% | Lifespan:≥50000H |
| Input Voltage:AC85V~265V | Efficiency:≥88% |
| Rated Power:36W | Beam Angle:270° |
| Actual Power:38W | Luminous:2880±100Lm |
| Working frequency:50/60Hz | Rendering Index:70Ra |
| Power Factor:0.95±0.02 | CCT:2700-2800K,6000-6500K |
| Operating temperature:-20°C~45°C | Size:1196mm (L)×D26mm |
| Warranty time:5 Year |
1500MM 48W
| Material:Aluminium Body+Milky | SMD:2835 |
| Light transmittance :≥80% | Lifespan:≥50000H |
| Input Voltage:AC85V~265V | Efficiency:≥88% |
| Rated Power:48W | Beam Angle:270° |
| Actual Power:49W | Luminous:3880±100Lm |
| Working frequency:50/60Hz | Rendering Index:70Ra |
| Power Factor:0.95±0.02 | CCT:2700-2800K,6000-6500K |
| Operating temperature:-20°C~45°C | Size:1496mm (L)×D26mm |
| Warranty time:5 Year |
2400MM 65W
| Material:Aluminium Body+Milky | SMD:2835 |
| Light transmittance :≥80% | Lifespan:≥50000H |
| Input Voltage:AC85V~265V | Efficiency:≥88% |
| Rated Power:65W | Beam Angle:270° |
| Actual Power:66W | Luminous:5200±100Lm |
| Working frequency:50/60Hz | Rendering Index:70Ra |
| Power Factor:0.95±0.02 | CCT:2700-2800K,6000-6500K |
| Operating temperature:-20°C~45°C | Size:2400mm (L)×D26mm |
| Warranty time:5 Year |
Features
- V shaped tube, two rows of leds,more brightness and 270 beam angle.
- Thickness aluminum shell and plastic cover, strong to delivery.
- Save power more than 90% compare with fluorescent tubes .
- High PF for power supply, constant electric current driver, Input AC90-265V.
- High lumen SMD2835 Sanan chip, 25lm/pcs. Pure colour, High CRI.
- Super underground parking lot.
- Basement/garage parking
- Indoor lighting & outdoor lighitng
Shipping:
- By UPS/DHL/FEDEX/TNT---3~5 days to arrive
- Air cargo---about 7days to arrive
- By sea---about one month to arrive
- Ways of transportation depend on your actual requirements.
- Payment: Western Union, PAYPAL, MoneyGram, T/T, 30% deposits-- 70% balance before delivery
- Delivery Time: 3-5 days for samples; 5-10 days for batch goods
- Shipping Port: Shenzhen, China(Mainland)
- Discounts: According to your quantities
- MOQ: >1 pieces.
- Warranty: 5 years
-Question: What is the Minimum Order Quantity(MOQ)?
Answer:>1 pcs per model.
-Question: What’s the brand of LED chip?
Answer: smd2835.
- Question: Is this light dimmable?
Answer: No,
- Question: May I buy samples from you?
Answer: Yes, samples available.
- Question: What’s the leading time? (How long do you need to prepare my goods?)
Answer: 2-3days for sample orders. 7-10days for mass production orders (based on different quantities).
- Question: How will you delivery my goods to me?
Answer: We always ship by international express, air and sea.
5-7 days for air transportation, 3-5 days for international express. 20-40 days for sea transportation.
- Question: What is your product quality?
Answer: Our raw materials are purchased from qualified suppliers. And we have a strong quality control team to guarantee our quality according to AQL standard. The quality control system: IQC→PQC→FQC→OQC. Every process will be checked strictly.
- Question: What is your waranty?
Answer: Our warranty is 5 years after delivery.
